Southbend (Middleby) 20072SB Platinum Undercounter & Worktop Refrigeration
Southbend (Middleby) 20072SB Platinum Undercounter & Worktop Refrigeration is backordered and will ship as soon as it is back in stock.
Documents
Related Searches
Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.
Southbend (Middleby) 20072SB Platinum Undercounter & Worktop Re...
Description
Southbend Platinum Series 72" Refrigerated Chef Base – Model 20072SB
Low-profile, self-contained unit with four 26" easy-glide drawersDesigned to sit directly beneath Southbend Platinum modular range tops, the 20072SB keeps up to eight full-size hotel pans of ingredients at food-safe temperatures—right on the cookline. Heavy-duty all-stainless construction, rapid-recovery refrigeration and an ultra-low 26" height make this chef base a space-saving, labor-saving powerhouse for any high-volume kitchen.
Why You’ll Love It
- 4 self-closing 26" drawers glide on stainless-steel rollers and feature full-width pull handles.
- Each drawer holds two standard 12" × 20" × 4" pans (pans not included) – 8 pans total.
- CFC-free R-404A refrigeration with expansion valve delivers rapid temperature recovery.
- Foamed-in-place polyurethane insulation provides maximum energy efficiency.
- 304 stainless steel top, front, sides, back, drawers and interior for unbeatable durability and easy sanitation.
- Coated mullion coils resist corrosion and ensure even cooling throughout the cabinet.
- Adjustable digital thermostat for precise temperature control.
- 6" adjustable stainless legs included; locking caster kit available for added mobility.
- UL & NSF listed for commercial kitchens; one-year parts & labor warranty.
Technical Specifications
| Model | 20072SB |
|---|---|
| Exterior Dimensions (W × D × H) | 72" × 32.5" × 26" (including 6" legs) |
| Drawers / Pan Capacity | 4 drawers / 8 full-size 12" × 20" × 4" pans |
| Cooled Volume | 13 cu. ft (0.37 m³) |
| Refrigerant | R-404A (CFC-free) |
| Cooling Capacity | 1,875 BTU/hr |
| Compressor | 1/3 HP, self-contained |
| Electrical | 120 V / 60 Hz / 1-ph, 10.1 A, NEMA 5-15P cord & plug |
| Shipping Weight | 650 lb (295 kg) |
| Clearance Required | 2" at rear for ventilation |
Factory Options (Sold Separately)
- Locking or all-directional caster kit
- Cable restraint kit (for use with casters)
- Electric condensate evaporator pan
- Caster frame (various heights)
Certifications & Warranty
- UL Certified
- NSF Certified
- One-year parts & labor warranty (commercial use)
Intended for commercial applications only. Minimum ambient temperature 55 °F; maximum 90 °F. Breaker sizing should be verified by a qualified electrician. Specifications subject to change without notice.
