Southbend (Middleby)  |  Platinum  |  SKU: 20064RSB

Southbend (Middleby) 20064RSB Platinum Undercounter & Worktop Refrigeration

$15,696.00
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options
Documents
Cutsheet Installation & operation Middleby financial flyer Owner's manual Warranty sheet
Related Searches
Commercial Work Tables Equipment Stands Kitchen Equipment Tables Restaurant Equipment

Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.

Description

Platinum Series 64" Remote Refrigerated Base

Southbend | Model 20064RSB | 4-Drawer Low-Height Unit

Keep high-volume ingredients perfectly chilled and right where you need them—directly beneath your Platinum Series cooktops. The Southbend 20064RSB remote refrigerated base delivers rock-solid temperature performance in a compact 26-inch-tall footprint that puts chefs closer to the action while maximizing ergonomic efficiency on the line.

Why You’ll Love It

  • Low-profile 26" height seamlessly supports any Platinum Series modular range top.
  • (2) 18" & (2) 26" heavy-duty, self-closing drawers glide on stainless steel rollers for years of trouble-free service.
  • Each drawer holds standard 12" × 20" × 4" hotel pans (pans not included) for a total of 6 full-size pans.
  • CFC-free, R-404A refrigeration with an expansion valve for rapid temperature recovery.
  • Foamed-in-place polyurethane insulation and corrosion-resistant coated mullion coils ensure even cooling.
  • All-stainless-steel construction—top, front, sides, back, drawers & interior—for unbeatable durability and easy cleaning.
  • Digital thermostat with LED display for precise, effortless control.
  • 6" adjustable stainless steel legs included; optional casters available.
  • UL & NSF listed for commercial kitchens; one-year parts & labor warranty.

Technical Specifications

External Dimensions 64" W × 32.5" D × 26" H (including 6" legs)
Drawers / Capacity (2) 18" & (2) 26" drawers | 6 full-size 12"×20"×4" pans | 13 ft³ cooled volume
Refrigeration Type Remote, 1/4 HP compressor (not included) | 1,875 BTU/hr cooling load
Electrical 120 V / 60 Hz / 1-phase | 3 A | 6 ft cord & plug
Refrigerant R-404A (CFC-free)
Construction 304 stainless steel exterior & interior; coved corners meet NSF 7
Controls Digital thermostat, adjustable set-point, LED readout
Shipping Weight Approx. 530 lb (240 kg)
Certifications UL, NSF
Warranty 1 year parts & labor

Popular Options & Accessories

  • Locking caster frame kit (front casters lock).
  • Cable restraint kit for mobile installations.
  • Electric condensate evaporator pan (various sizes).
Important: This unit ships ready for connection to a remote condenser system (condenser not included). A 1/2" condensate drain tube exits the right side; minimum 2" rear clearance is required.

Need easy monthly payments? Ask about Middleby Equipment Financing for fast approvals and potential Section 179 tax advantages.

Features & Specs

Manufacturer

Southbend (Middleby)

Brand_name

Platinum

Certifications

NSF, UL

Height

26.0in

Width

64.0in

Depth

32.5in

Shipping Weight

585.0lbs

Top Finish

stainless steel top

Drawer Qty

4 drawers

Width

61" - 72" wide

Exterior Finish

all stainless steel exterior

Compressor HP

1/4 HP

Refrigeration

remote (refrigeration not included)

Specifications

Refrigerator Base, remote, low height, 64", (2) 18" & (2) 26" self-closing drawers, full width pull handles, stainless steel exterior & 6" legs, 120v/60/1-ph, 3 amps, 1/4 HP, order with Platinum Series modular cook tops, UL, NSF
