Scotsman 15-Inch Air-Cooled Undercounter Flake Ice Machine with 36 lb Storage Bin

SKU: UF0915AX-1
GTIN: 840315405134
$3,664.00
/each
Free Shipping
Expected delivery date of ,
if ordered within hours and minutes
Not Shipping to ?
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

Related Searches

Best Sellers Commercial Ice Makers Ice Machines Ice Machines & Ice Equipment Ice Machines with Bins Ice Makers & Bins New Arrivals Refrigeration, Freezing & Ice Restaurant Equipment Scotsman

Scotsman 15-Inch Air-Cooled Undercounter Flake Ice Machine with 36 lb Storage Bin

Self-Contained, Front-Breathing, ADA-Capable

A compact undercounter flake ice machine that delivers reliable daily output and built-in storage in a slim 15-inch footprint.

  • Produces up to 96 lb of flake ice per day and stores 36 lb in the integrated bin.
  • 15-inch-wide front-breathing design fits tight spaces with no side clearance required.
  • Sealed maintenance-free bearings and stainless steel auger and evaporator help maximize reliability.
  • ADA-capable with the optional floor mount kit for undercounter installations.
  • Includes a power cord with NEMA 5-15P plug, ice scoop, adjustable legs, and a unit-specific QR code for service information.

Overall Dimensions:

15.0"W x 24.0"D x 38.0"H

Product Weight:

108.0 lb

Space-Saving Undercounter Footprint

Only 15 inches wide with front-breathing airflow, so it fits tight locations without side clearance.

Reliable Ice-Making Components

Sealed maintenance-free bearings plus a stainless steel auger and evaporator help reduce maintenance and support long service life.

High Output and Bin Storage

Produces up to 96 lb per 24 hours and stores 36 lb of flake ice in the built-in bin.

Ergonomic Slide-Back Door

Provides easy access to ice in the storage bin.

ADA-Capable Installation

The optional floor mount kit allows installation under 34-inch ADA counters and lowers overall height to 31.9 inches.

Quick Service Access

A unit-specific QR code provides fast access to service manuals, cleaning guides, and warranty history.

Durable Cabinet Construction

Rust-free front panel and corrosion-resistant aluminum alloy side panels help extend cabinet life.

Energy-Efficient Refrigeration

Uses non-ozone-depleting R290 refrigerant and is ENERGY STAR certified.

Type Ice Machine With Bin
Style Flake
Installation Type Undercounter
Refrigeration Type Air-Cooled
Capacity 36 lb
Production Capacity 96 lb per 24 Hours
Voltage 115 Volts
Hertz 60 Hz
Phase 1-Phase
Plug Type NEMA 5-15P
Breaker Size 15 Amps
BTU 1,500 BTU per Hour
Refrigerant Type R290
Water Inlet Size 1/4-Inch Plastic Tubing
Drain Connection Size 3/4-Inch FPT
Country of Origin USA
Shipping Width 22 Inches
Shipping Depth 27 Inches
Shipping Height 38 Inches
Shipping Weight 108 lb
Selling Unit Each
Units Per Case 1

Certifications & Compliance

Certified badge of Energy Star Certified
Energy Star Certified
Certified badge of NSF Certified
NSF Certified

Warranty & Protection

3 years parts and labor on all components.

Documents

PDF Cutsheet PDF Download PDF Manual PDF Download PDF Installation & service manual PDF Download

Frequently Asked Questions

It produces up to 96 lb per 24 hours under 70°F air and 50°F water conditions, with 76 lb AHRI certified output at 90°F air and 70°F water.
The built-in storage bin holds 36 lb of ice.
It uses 115 Volts, 60 Hz, 1-phase power and includes a NEMA 5-15P plug. The maximum fuse size or HACR breaker is 15 amps.
The potable water inlet uses 1/4-inch plastic tubing and the drain connection is 3/4-inch FPT.
No side clearance is required for operation because it is front-breathing. Recommended minimum clearances are 1/8 inch on the sides, 1/4 inch on top, and 4 inches in the back.
Yes, with the optional KUFM15 floor mount kit. It lowers the overall height to 31.9 inches for ADA applications.
