Customize Royal Range of California Model no. TB-846
Royal Range of California Turbo Broiler TB-846 Countertop Gas Charbroiler, Radiant, Manual Controls, 46.5-inch
The TB-846 is a countertop gas infrared radiant broiler with eight burners, manual controls, and a 23 in W x 43 in D broiling grid. It uses removable stainless steel radiants and cast iron grates.
The all-welded frame includes 1,200°F mineral wool insulation. The unit has a stainless steel front, ends and side splash, a front valve panel, 4 in legs, and a total input of 116,000 BTU.
- Gas operation for natural gas or LP gas
- Individual burner controls every 6 in
- Full-width removable stainless steel crumb pan
- Standing pilots and stainless steel burner and pilot tubing
Overall Dimensions:
46.5"W x 28.5"D x 14.0"HProduct Weight:
369.0 lbInfrared radiant heating
Removable stainless steel radiants produce infrared rays for radiant broiling.
Eight gas burners
The TB-846 is listed with eight burners rated at 14,500 BTU/hr each, for 116,000 BTU total.
Manual burner controls
Individual burner controls are provided every 6 in.
All-welded insulated frame
The frame is fully welded and includes 1,200°F mineral wool insulation.
Cast iron grates
Heavy-duty cast iron reversible top grates are elevated at the rear with a cast-in foot.
Removable crumb pan
A full-width removable stainless steel crumb pan is included.
Stainless steel exterior
The front, ends and side splash are stainless steel, with a front valve panel.
Standing pilots
Standing pilots provide the specified ignition system.
Certifications & Compliance
Warranty & Protection
Supplied product documents state a two-year limited warranty, but labor coverage differs between the documents.
