Customize Royal Range of California Model no. TB-841
Royal Range of California Turbo Broiler TB-841 Countertop Gas Charbroiler, Radiant Heat, Manual Controls, 41-1/8" Wide
The TB-841 is a countertop gas charbroiler with radiant heat, manual controls, and a 41-1/8-inch-wide cooking area.
- Heating: Seven burners provide 101,500 BTU of gas input beneath removable welded stainless steel radiants.
- Cooking surface: The broiling grid measures 23 x 38 inches and uses cast iron grates elevated at the rear.
- Construction: The unit has a fully welded frame, 1,200°F mineral wool insulation, a stainless steel front, ends and side splash, and a front valve panel.
- Installation: The countertop broiler has 4-inch legs and a 3/4-inch NPT gas connection at the right-hand rear.
Overall Dimensions:
41.13"W x 28.5"D x 14.0"HProduct Weight:
322.0 lbRadiant heating
Removable, heavy-gauge welded stainless steel radiants produce infrared rays.
Manual burner controls
Individual burner controls are arranged every 6 inches.
Burner system
Seven heavy cast iron burners are rated at 14,500 BTU/hr each, for 101,500 BTU total.
Cast iron grates
Heavy-duty cast iron grates are elevated at the rear and include a cast-in foot.
Welded construction
The frame is fully welded and includes 1,200°F mineral wool insulation.
Cleaning components
A full-width removable stainless steel crumb pan is provided.
Exterior construction
The front, ends and side splash are stainless steel, with a front valve panel.
Gas connection
The 3/4-inch NPT gas connection is located at the right-hand rear of the appliance.
Certifications & Compliance
Warranty & Protection
Two-year limited warranty covering parts and labor.
