Royal Range of California Royal Series RSRB-30 30-Inch Gas Countertop Charbroiler, Radiant, Manual Controls, Cast-Iron Grates

SKU: RSRB-30
$4,193.00
/each Configurable
Enter ZIP for a shipping estimate

Want to speak to an expert?

The RSRB-30 is a 30-inch gas countertop charbroiler with radiant heat and manual controls. It uses five burners with a total input of 62,500 BTU and includes heavy-duty cast-iron top grates.

  • Continuous pilots and individually adjustable burners
  • Stainless steel sides and front valve cover
  • Full-width removable stainless steel crumb pan under the broiler
  • 4-inch adjustable heavy-duty legs included

Overall Dimensions:

30.0"W x 25.5"D x 14.0"H

Product Weight:

260.0 lb

Radiant heating

Provides radiant heat for gas charbroiling.

Manual controls

Uses manual controls with continuous pilots.

Five-burner system

Includes five stainless steel tubular burners rated at 12,500 BTU/hr each, for 62,500 BTU total input.

Individually adjustable burners

Each burner can be adjusted independently.

Cast-iron grates

Includes heavy-duty cast-iron top grates.

Removable crumb pan

A full-width removable stainless steel crumb pan is positioned under the broiler.

Adjustable legs

Includes 4-inch adjustable heavy-duty legs.

Stainless steel components

Includes stainless steel sides and a stainless steel front valve cover.

Product type Charbroiler
Fuel type Gas
Installation type Countertop
Heating type Radiant
Control type Manual controls
Pilot system Continuous pilots
Cooking surface 18 in.
Number of burners 5
Burner construction Stainless steel tubular burners
Burner input 12,500 BTU/hr each
Total input 62,500 BTU
Grate material Cast iron
Legs 4 in. adjustable heavy-duty legs included
Gas connection 3/4 in. NPT on the right-hand rear of the appliance
Gas pressure 5 in. W.C. natural gas; 10 in. W.C. propane
Installation clearance Non-combustible locations only; 0 in. rear and sides

Frequently Asked Questions

The RSRB-30 is a gas charbroiler. The product documentation lists natural gas and propane gas-pressure specifications.
It has five burners rated at 12,500 BTU/hr each, for a total input of 62,500 BTU.
The RSRB-30 measures 30 in. wide by 25.5 in. deep by 14 in. high and weighs 260 lb.
It includes heavy-duty cast-iron top grates.
No. The cutsheet specifies installation in non-combustible locations only, with zero-inch rear and side clearances.
The 3/4 in. NPT gas connection is on the right-hand rear of the appliance.
