Royal Range of California Delux Series RDSA-24 Countertop Gas Griddle, 24" W, 1" Thick Smooth Steel Plate, Thermostat Controls

SKU: RDSA-24
$6,484.00

Want to speak to an expert?

The Royal Range of California Delux Series RDSA-24 is a countertop gas griddle with a 24-inch cooking surface and a 1-inch thick polished steel plate.

  • Two burners with solid-state snap-action thermostat controls provide 60,000 BTU total.
  • The 4-inch stainless steel grease trough has a large drain opening.
  • The all-welded frame includes 1,200°F mineral wool insulation.
  • Stainless steel sides and a front valve cover support the appliance construction.
  • Four-inch adjustable heavy-duty legs are included.

Overall Dimensions:

24.0"W x 34.0"D x 11.0"H

Product Weight:

260.0 lb

24-inch cooking surface

Provides a 24-inch-wide cooking surface in a countertop configuration.

Polished steel griddle plate

The griddle plate is 1 inch thick with a smooth polished steel cooking surface.

Solid-state thermostatic controls

Two solid-state snap-action thermostats control the two burners.

60,000 BTU gas input

The two-burner configuration is rated at 60,000 BTU total.

Grease management

A 4-inch stainless steel grease trough includes a large drain opening.

Welded insulated frame

The all-welded frame includes 1,200°F mineral wool insulation.

Stainless steel exterior components

The unit has stainless steel sides and a stainless steel front valve cover.

Adjustable legs

Four-inch adjustable heavy-duty legs are included.

Product Line Delux Series
Product Type Gas griddle
Installation Type Countertop
Fuel Type Gas
Cooking Surface Width 24 in
Cooking Surface Depth 24 in
Griddle Plate Thickness 1 in
Griddle Plate Finish Smooth polished steel
Controls Solid-state snap-action thermostats
Number of Thermostats 2
Number of Burners 2
Total BTU 60,000 BTU
Grease Trough Width 4 in
Exterior Finish Stainless steel front and sides
Frame Construction All-welded
Insulation 1,200°F mineral wool
Leg Height 4 in adjustable heavy-duty legs
Electrical 120 V, 60 Hz, 1 phase, 1 A
Gas Connection 3/4 in NPT

Frequently Asked Questions

Yes. The RDSA-24 is a countertop gas griddle.
It has two burners and two solid-state thermostats.
The total BTU rating is 60,000 BTU.
The cooking surface is 24 inches wide and 24 inches deep, with a 1-inch thick smooth polished steel plate.
The product measures 24 inches wide by 34 inches deep by 11 inches high and weighs 260 pounds.
The specified electrical service is 120 V, 60 Hz, single phase, 1 A.
The gas connection is 3/4-inch NPT.
