Royal Range of California Delux Series RDR-12-C 72-Inch Gas Restaurant Range with 12 Open Burners, Standard & Convection Ovens
SKU: RDR-12-C
$18,553.00
The RDR-12-C is a 72-inch gas restaurant range with 12 open burners, one convection oven, and one standard oven.
- Each open burner is rated at 30,000 BTU.
- 12-inch by 12-inch cast iron grates support the cooking surface.
- The unit has an all-stainless-steel burner box and a fully welded frame with 1,200°F mineral wool insulation.
- Stainless steel is used on the front, sides, valve cover, kickplate, and 11-inch-deep high shelf.
- The ovens include an oven safety valve.
Overall Dimensions:
72.0"W x 40.5"D x 56.5"HProduct Weight:
1280.0 lbOpen Burners
Includes 12 lift-off open burners rated at 30,000 BTU each.
Dual Oven Configuration
Combines one standard oven with one convection oven.
Cast Iron Grates
Uses 12-inch by 12-inch cast iron top grates.
Stainless Steel Burner Box
The burner box is constructed from stainless steel.
Welded and Insulated Frame
Features a fully welded frame with 1,200°F mineral wool insulation.
Stainless Steel Exterior
The front, sides, valve cover, kickplate, and high shelf are stainless steel.
High Shelf
Includes an 11-inch-deep high shelf.
Oven Safety Valve
Includes an oven safety valve.
Series
Delux Series
Equipment Type
Restaurant range
Fuel
Gas
Open Burners
12
Burner Input
30,000 BTU each
Oven Configuration
1 standard oven; 1 convection oven
Total Input
425,000 BTU
Grates
12 in x 12 in cast iron
Burner Box
Stainless steel
Frame
Fully welded
Insulation
1,200°F mineral wool
Exterior
Stainless steel front, sides, valve cover, and kickplate
High Shelf
11 in deep
Oven Safety Valve
Yes
Gas Connection
3/4 in NPT, right-hand rear
Convection Oven Electrical
120 V, 50/60 Hz, 1-phase, 8 A
Certifications & Compliance
Warranty & Protection
Two-year parts and labor limited warranty.
Frequently Asked Questions
The RDR-12-C has 12 open burners, each rated at 30,000 BTU.
It has one standard oven and one convection oven.
The range is 72 inches wide, 40.5 inches deep, and 56.5 inches high, with a listed weight of 1,280 pounds.
The cooking surface uses 12-inch by 12-inch cast iron grates.
The listed total input is 425,000 BTU.
The product is covered by a two-year limited warranty for parts and labor, subject to the manufacturer's stated conditions.
