Royal Range of California Delux Series RD85-24 Countertop Gas Griddle, 24"W x 24"D, 1" Smooth Steel Plate, Thermostat Controls

SKU: RD85-24
$6,617.00

Want to speak to an expert?

The Royal Range of California Delux Series RD85-24 is a countertop gas griddle with a 24 in. wide by 24 in. deep cooking surface. It features a 1 in. thick polished steel griddle plate, a 3 in. grease trough, and two solid-state snap-action thermostat controls.

  • Stainless steel front, sides, and back
  • Fully welded frame
  • Two burners rated at 64,000 BTU total
  • Four-inch legs with adjustable feet

Overall Dimensions:

24.0"W x 33.63"D x 14.0"H

Product Weight:

285.0 lb

Polished steel griddle plate

The cooking surface uses a 1 in. thick polished steel plate with a smooth finish.

Solid-state thermostat controls

Two solid-state snap-action thermostat controls are provided, with adjustment from 150°F to 450°F.

Gas heating

The griddle has two burners with a total rated output of 64,000 BTU.

Grease management

A 3 in. grease trough is integrated into the griddle plate.

Stainless steel exterior

The front, sides, and back are stainless steel.

Welded construction

The frame is fully welded.

Adjustable legs

Four-inch legs with adjustable feet are included.

Product Type Griddle
Installation Type Countertop
Fuel Type Gas
Cooking Surface 24 in. W x 24 in. D
Plate Thickness 1 in.
Griddle Plate Finish Smooth polished steel
Grease Trough 3 in.
Controls Two solid-state snap-action thermostat controls
Temperature Range 150°F–450°F
Number of Thermostats 2
Number of Burners 2
Total Input 64,000 BTU
Exterior Finish Stainless steel front, sides, and back
Frame Construction Fully welded
Legs 4 in. legs with adjustable feet
Electrical 120V, 60 Hz, 1 phase, 1 amp
Power Cord 6 ft. cord with standard 3-prong grounded plug
Gas Connection 3/4 in. NPT, right-hand rear
Rear Clearance 6 in. combustible; 0 in. non-combustible
Side Clearance 4 in. combustible; 0 in. non-combustible

Frequently Asked Questions

The cooking surface is 24 in. wide by 24 in. deep.
The griddle plate is 1 in. thick and has a polished smooth steel finish.
The RD85-24 has two solid-state thermostat controls and two burners.
The total rated output is 64,000 BTU.
The listed overall dimensions are 24 in. wide, 33.63 in. deep, and 14 in. high.
The specification is 120V, 60 Hz, single phase, 1 amp, with a 6 ft. standard 3-prong grounded power cord.
