Royal Range of California Royal Series RARB-24 24-Inch Gas Countertop Charbroiler with Radiant Heat and Manual Controls

SKU: RARB-24
$5,269.00
/each Configurable
Enter ZIP for a shipping estimate
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

Related Searches

Best Sellers Charbroilers Charbroilers & Grills Commercial Charbroilers Commercial Grills Cooking Equipment Equipment Gas Charbroilers New Arrivals Restaurant Equipment Royal Range of California

The Royal Range of California RARB-24 is a 24-inch gas countertop charbroiler with radiant heat, manual controls with pilot, and an 80,000 BTU input.

  • One manually adjustable cast iron grate section with five-position tilt adjustment
  • Four individually controlled burners
  • Removable and replaceable independent firebox assembly
  • Stainless steel sides and front valve cover
  • Full-width removable stainless steel crumb pan

Overall Dimensions:

24.0"W x 31.5"D x 18.0"H

Product Weight:

275.0 lb

Radiant gas heat

Uses gas-fired radiant heating for charbroiling.

Manual controls with pilot

Burners are individually controlled by manual valves and use standing pilots.

Adjustable cast iron grate

The single cast iron grate section provides five cooking-position tilt adjustments.

Four burners

The RARB-24 has four stainless steel burners rated at 20,000 BTU/hr each.

Removable firebox

The independent firebox assembly is fully welded, removable, and replaceable.

Stainless steel exterior components

The sides and front valve cover are stainless steel.

Removable crumb pan

A full-width removable stainless steel crumb pan is provided.

Double-wall side panels

Double-wall panels are used on the sides.

Product type Gas charbroiler
Installation type Countertop
Heating type Radiant
Control type Manual controls with pilot
Burners 4
Burner rating 20,000 BTU/hr each
Total input 80,000 BTU
Grate section 1 manually adjustable cast iron section
Grate adjustment 5-position cooking grate tilt adjustment
Cooking surface depth 24 in
Overall width 24.0 in
Overall depth 31.5 in
Overall height 18.0 in
Weight 275 lb
Gas connection 3/4 in NPT, right-hand rear
Gas pressure 5 in W.C. natural gas; 10 in W.C. propane
Installation clearance For non-combustible location only
Rear clearance 0 in for non-combustible location
Side clearance 0 in for non-combustible location

Certifications & Compliance

Certified badge of CSA Certified
CSA Certified

Warranty & Protection

Two-year parts and labor limited warranty.

Documents

PDF Cutsheet PDF Download PDF Cutsheet PDF Download PDF Cutsheet PDF Download PDF Owner's manual PDF Download PDF Owner's manual PDF Download PDF Warranty sheet PDF Download PDF Warranty sheet PDF Download

Frequently Asked Questions

The RARB-24 uses radiant gas heating.
It has four burners, each rated at 20,000 BTU/hr.
The total input is 80,000 BTU.
It uses manual controls with standing pilots and individually controlled manual valves.
The product is 24.0 inches wide, 31.5 inches deep, and 18.0 inches high.
It has a 3/4-inch NPT gas connection at the right-hand rear of the appliance. The listed pressure is 5 inches W.C. for natural gas and 10 inches W.C. for propane.
Royal Range of California provides a two-year parts and labor limited warranty, subject to its stated conditions. Cast iron parts are warranted for 90 days.
