Randell RCHB-2-208-AF Custom & Serving Steam Tables & Food Wells
Randell RCHB-2-208-AF Custom & Serving Steam Tables & Food Wells is backordered and will ship as soon as it is back in stock.
Documents
Related Searches
Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.
Randell RCHB-2-208-AF Custom & Serving Steam Tables & Food ...
Description
Randell RCHB-2-AF Drop-In Hot/Cold Combo Well – 2-Pan, Auto-Fill
Instantly swap from chilled salads to piping-hot entrées at the flip of a switchBuilt for busy serving lines, the RCHB-2-AF combines a refrigerated cold pan and an electrically-heated water-bath well in one seamless stainless-steel module. Automatic water fill, intuitive controls and eco-friendly R-290 refrigeration make this American-made unit the easiest way to add true all-day menu flexibility to your counter.
Key Advantages
- Dual-mode design meets NSF 7 for <41 °F cold holding and NSF 4 for 140-165 °F hot holding.
- Front rocker switch selects HOT or COLD; separate electronic thermostats ensure precise temperatures.
- Factory-installed auto water-fill keeps the hot well at the perfect level—no manual monitoring.
- Common 1" drain with stainless gate valve speeds change-overs and clean-up.
- Self-contained, SNAP-compliant R-290a system (0 ODP / 3 GWP) with energy-efficient electronic control.
- 18-ga. stainless top & coved-corner interior resist corrosion, chemicals and daily pan changes.
- Exclusive easy-mount system, remote control panel and louver panel simplify installation.
- Made in the USA and fully certified (cULus, NSF).
Perfect For
- Chef service counters & action stations
- Self-service buffets & salad bars
- Hospital & school tray-make lines
- Convenience store build-to-order programs
Specification Snapshot
| Model | RCHB-2-AF |
|---|---|
| Pan Capacity | (2) 12" × 20" full-size pans, 6" deep (adapter bars included) |
| Mode Selection | HOT (water bath) / COLD (refrigerated) via rocker switch |
| Temperature Range | Cold ≤ 41 °F • Hot 140-165 °F holding |
| Heating Output | 1,100 W (1.1 kW) |
| Refrigeration | R-290a, 1/4 HP, self-contained |
| Electrical | 208-240 V, 1-ph • 5.3 A @ 208 V / 4.5 A @ 240 V (heat) | 3.5 A @ 120 V (refrig) |
| Auto Water Fill | Yes (factory installed) |
| Drain | 1" NPT with stainless gate valve |
| Cutout Size | 32-1/4" W × 25" D |
| Overall Dimensions | 33-11/16" W × 26-1/8" D × 28-3/4" H (to drain) |
| Shipping Weight | 120 lb |
| Certifications | cULus, NSF/ANSI 4 & 7, SNAP compliant |
| Country of Origin | Made in USA |
Includes 1-year parts & labor warranty with additional compressor coverage available—see Randell warranty terms for details.
