Randell  |  Custom & Serving  |  SKU: 9560-2AWF

Randell 9560-2AWF Custom & Serving Steam Tables & Food Wells

$4,705.50
Expected delivery date of , to your door
if ordered within hours and minutes
Not Shipping to ?
More Delivery Options
Documents
Cutsheet Cutsheet Owner's manual Warranty sheet
Related Searches
Food Holding & Warming Equipment Steam Tables & Food Wells

Reach out via chat, email, or phone—we're here to help make sure it's the right fit for your kitchen. Contact us for more information.

Description

Randell 9560-2DM Drop-In Hot Food Well with Auto-Water Fill

2-well, wet-operation module for dependable, high-volume holding

Give every menu item the perfect finish-line home with Randell’s American-made 9560-2DM. This self-contained drop-in hot well automatically maintains water level, provides precise thermostatic control for each pan, and drains through a factory-installed manifold—so staff can focus on serving, not babysitting equipment.

Key Advantages

  • Auto-water fill keeps the bath at the ideal level all day—no manual refills.
  • Two sealed 12" × 20" wells, each with its own true thermostatic dial for pinpoint temperature control.
  • 18-gauge stainless steel top with die-stamped, raised sanitary rims prevents drips below the counter.
  • Fully insulated, corrosion-resistant steel body maximizes heat retention and energy efficiency.
  • Factory-installed drains manifold to a common gate valve for fast, mess-free emptying.
  • Pre-wired stainless control panel mounts in the counter front—single-point electrical hook-up simplifies installation.
  • UL, cULus & NSF listed for peace-of-mind compliance; proudly Made in the USA.

At-a-Glance Specs

Pan capacity 2 full-size (12" × 20" × 6 1⁄2")
Overall dimensions 31.75" L × 26" W
Counter cut-out 29.875" L × 22.5" W
Control panel cut-out 14.25" L × 5.75" H × 6" D
Well depth 6.5"
Electrical load 2.2 kW; 18.4 A @ 120 V | 10.6 A @ 208 V | 9.2 A @ 240 V, single phase
Water connection 1⁄4" NPT (auto-fill)
Drain connection Common 1⁄2" NPT gate valve
Construction 18-ga. stainless top; insulated corrosion-resistant steel body
Certifications UL, cULus, NSF
Approx. shipping weight 100 lb / 45 kg
Installation note: Unit ships pre-wired to a junction box and must be hard-wired by a qualified electrician. Water supply & drain connections are required for proper operation.

Hotel pans, adapter bars and mounting hardware are sold separately.

Features & Specs

Manufacturer

Randell

Brand_name

Custom & Serving

Certifications

NSF, UL, Made in USA

Width

34.01in

Depth

26.0in

Shipping Weight

85.0lbs

Style

individual pans

Controls

thermostatic controls

Construction

stainless steel top, corrosion resistant steel exterior

Insulated or Non-Insulated

insulated

Drain

with drain

Pan Capacity

(2) full size (12" x 20")

Wet or Dry operation

wet

Specifications

Drop-In Hot Food Unit, electric, (2) 12" x 20" pan size, auto-water fill, wet operation, individual thermostatic control, stainless steel top, corrosion resistant steel exterior, with drain and common gate valve, 2.2kW, cUL, UL, NSF, Made in USA
