Randell 9560-1-D Custom & Serving Steam Tables & Food Wells
Description
Randell 9560-1D Drop-In Hot Food Well
Single 12" × 20" sealed well • Wet operation • Thermostatic control • Made in USADesigned for custom serving counters and buffet lines, the Randell 9560-1D keeps one full-size steam-table pan at food-safe temperatures all service long. A true thermostatic system, factory-sealed well, and rugged stainless construction deliver the performance and durability trusted by operators nationwide.
Why You’ll Love It
- Holds one standard 12" × 20" × 6½" pan (or fractional pans with adaptor bars).
- One-piece 18 ga. stainless-steel top with die-stamped opening and raised sanitary rim.
- Wet-only sealed well for rapid, even heat transfer—no hot or cold spots.
- Remote stainless control panel with true thermostatic dial and lighted on/off power indicator.
- Fully insulated, corrosion-resistant exterior keeps heat in the well and out of your counter.
- Factory-installed drain & gate valve for quick, safe water removal.
- Pre-wired to a junction box for simple single-point field connection.
- cULus & NSF listed; proudly built in the USA.
Technical Specifications
| Pan capacity | (1) full-size 12" × 20" pan |
|---|---|
| Operation | Wet (water bath) |
| Heat output | 1.1 kW electric element |
| Voltage options | 120 V / 1-ph / 9.2 A • 208 V / 1-ph / 5.3 A • 240 V / 1-ph / 4.6 A |
| Overall dimensions | 18.5" W × 26" D |
| Counter cut-out | 16.125" W × 22.5" D |
| Well depth | 6.5" |
| Shipping weight | ≈ 60 lb |
| Certifications | UL, cUL, NSF |
| Country of origin | USA |
Perfect For
- Restaurant serving lines & self-serve buffets
- School & university cafeterias
- Healthcare & corporate dining rooms
- Hotel breakfast or banquet service
- Custom mobile or stationary catering counters
What’s Included
- Factory-sealed hot well with drain & gate valve
- Remote stainless control panel & pre-wired junction box
- User/installation manual
- 1-year parts & labor warranty
Popular Accessories (sold separately)
- Adaptor bars for fractional pans
- Extended thermostatic lead
- Low-wattage 500 W element kit
- Automatic water-fill system
Need additional wells? Check out Randell models 9560-2 through 9560-6 for multi-well configurations.
