Piper Products/Servolift Eastern

Piper Products/Servolift Eastern Elite 5-HF-HIB Mobile Electric Hot Food Serving Counter, 74"W, 5 Sealed Wells, Enclosed Heated Base

SKU: 5-HF-HIB
$14,195.28
/each
Enter ZIP for a shipping estimate
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

Related Searches

Best Sellers Equipment Food Holding & Warming Equipment Food Warmers & Holding Equipment Heated Serving Counters New Arrivals Piper Products/Servolift Eastern Restaurant Equipment Serving & Display Equipment Serving Counters

The 5-HF-HIB is an electric Elite hot food serving counter measuring 74 in. wide, 28 in. deep, and 36 in. high. Its five sealed wells each use a 1000 W element and thermostat.

The mobile modular unit has an enclosed heated base with pan slides, a 14-gauge stainless steel top, stainless steel front and end panels, manifold drains, and 5 in. casters. The heated base includes two pan rack assemblies for full-size 12 x 20 pans.

  • 7 kW electrical rating.
  • 208 V or 240 V, single-phase configurations are specified for this model.
  • NSF and UL certifications are specified.

Overall Dimensions:

74.0"W x 28.0"D x 36.0"H

Product Weight:

375.0 lb

Sealed hot food wells

Five sealed wells are provided, each with a 1000 W heating element and thermostat.

Enclosed heated base

The heated base includes pan slides and two pan rack assemblies for storage beneath the wells.

Pan rack storage

Each pan rack assembly accommodates six 2-1/2 in. deep pans, three 4 in. deep pans, or two 6 in. deep pans in full-size 12 x 20 pans.

Mobile modular design

The counter has an interlocking mechanism and 5 in. casters.

Stainless steel construction

The top is 14-gauge stainless steel, with stainless steel front and end panels.

Drainage

Manifold drains are standard; the cutsheet specifies a 3/4 in. FPT drain valve.

Electrical system

The model is rated at 7 kW, with 208 V or 240 V single-phase configurations specified.

Brand Elite
Equipment Type Electric hot food serving counter
Design Mobile modular; interlocking mechanism
Well Count 5
Well Type Sealed well
Well Heating 1000 W element with thermostat per well
Total Power 7 kW
Electrical Configuration 208 V or 240 V, single phase
Current Draw 33.6 A at 208 V; 29.2 A at 240 V
Plug NEMA 6-50P at 208 V and 240 V
Top Construction 14-gauge stainless steel
Front and End Panels Stainless steel
Base Design Enclosed heated base with pan slides
Pan Rack Assemblies 2
Pan Rack Capacity Each assembly: 6 pans 2-1/2 in. deep, 3 pans 4 in. deep, or 2 pans 6 in. deep; full-size 12 x 20 pans
Drain Manifold drains standard; 3/4 in. FPT drain valve
Caster Size 5 in.

Certifications & Compliance

Certified badge of NSF Certified
NSF Certified
Certified badge of UL Certified
UL Certified

Warranty & Protection

Limited 12-month warranty on parts and labor.

Documents

PDF Cutsheet PDF Download PDF Warranty sheet PDF Download

Frequently Asked Questions

It has five sealed wells, each with a 1000 W element and thermostat.
Yes. It has an enclosed heated base with pan slides and two pan rack assemblies.
The counter is 74 in. wide, 28 in. deep, and 36 in. high.
The unit is rated at 7 kW. The cutsheet specifies 208 V or 240 V, single-phase configurations, with 33.6 A at 208 V and 29.2 A at 240 V.
Piper Products provides a limited 12-month warranty on parts and labor, subject to the manufacturer's warranty terms.
