Penn Scale Ohaus® EXP4202 Analytical Balance, 4200 g Capacity, 0.01 g Readability, 178 × 201 mm Weighing Pan

SKU: EXP4202
$4,500.30
/each
Enter ZIP for a shipping estimate
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

Related Searches

Best Sellers Equipment Food Preparation Equipment Food Scale Parts & Accessories Food-Scale Components New Arrivals Penn Scale Restaurant Equipment Restaurant Equipment Parts

The EXP4202 is an Explorer Plus precision balance with a 4,200 g capacity, 0.01 g readability, and a 178 mm × 201 mm trapezoid weighing pan.

  • Touchscreen control: 7-inch TFT color touchscreen with glass overlay and detachable terminal.
  • Leveling: Motorized leveling system with digital leveling bubble.
  • Connectivity: USB Host, USB Device, Ethernet, and RS232 connections.
  • Operation: Two touchless sensors and selectable 7-color terminal status lights.

Overall Dimensions:

229.0"W x 229.0"D x 229.0"H

Product Weight:

7.7 lb

High-capacity weighing

Provides a 4,200 g capacity with 0.01 g full-range readability.

Trapezoid weighing pan

Includes a 178 mm × 201 mm weighing pan.

Motorized leveling

Uses a motorized leveling system with digital leveling bubble.

Color touchscreen terminal

Features a 7-inch TFT 16.7M color touchscreen with glass overlay and detachable terminal.

System connectivity

Provides two USB Host Type A ports, one USB Device Type B port, one USB Device Type C port, one Ethernet RJ45 port, and one RS232 port.

Touchless operation

Includes two touchless sensors on the terminal.

Selectable status lighting

Provides 7-color selectable terminal status lights.

Weighing applications

Supports basic weighing, parts counting, check counting, percent weighing, check weighing, dynamic weighing, totalization, formulation, differential, density determination, peak hold, pipette adjustment, SQC, fill weight variation, and flow rate control.

Capacity 4,200 g
Readability 0.01 g
Repeatability, typical at ≤5% of full load 0.007 g
Repeatability, 5% of full load to full range 0.01 g
Linearity deviation, typical 0.006 g
Linearity deviation 0.02 g
Stabilization time, typical ≤1 second
Weighing units g, ct, N, oz, ozt, Grain, dwt, mo, msg, tl H, tl S, tl T, tcl, tola, baht, lb, kg, Custom 1, Custom 2
Applications Basic weighing, parts counting, check counting, percent weighing, check weighing, dynamic weighing, totalization, formulation, differential, density determination, peak hold, pipette adjustment, SQC, fill weight variation, flow rate control
Display 7-inch TFT 16.7M color touchscreen with glass overlay, detachable terminal
Display resolution 800 × 480 pixels
Communication USB Host Type A ×2, USB Device Type B ×1, USB Device Type C ×1, Ethernet RJ45 ×1, RS232 ×1
Leveling system Motorized leveling system with digital leveling bubble
Weighing pan Trapezoid pan, 178 mm × 201 mm
Environmental sensors Temperature, relative humidity, and air pressure sensors
Touchless sensors 2 touchless sensors on the terminal
Terminal status lights 7-color selectable
Power input 100–240 VAC, 0.5 A, 50–60 Hz
Power output 12 VDC, 1.5 A

Certifications & Compliance

Documents

PDF Cutsheet PDF Download

Frequently Asked Questions

The EXP4202 has a capacity of 4,200 g.
The full-range readability is 0.01 g.
It uses a 178 mm × 201 mm trapezoid weighing pan.
It has a 7-inch TFT 16.7M color touchscreen with glass overlay and a detachable terminal.
Connectivity includes two USB Host Type A ports, one USB Device Type B port, one USB Device Type C port, one Ethernet RJ45 port, and one RS232 port.
The specified power input is 100–240 VAC, 0.5 A, 50–60 Hz.
