Penn Scale Ohaus® D52XW5WQS5 Washdown Stainless Steel Digital Bench Receiving Scale, Legal for Trade, 10" x 10" Platform

SKU: D52XW5WQS5
$1,972.66
/each
Enter ZIP for a shipping estimate
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

Related Searches

Best Sellers Commercial Food Scale Commercial Food Scales Equipment Food Prep Equipment Food Preparation Equipment New Arrivals Penn Scale Receiving Scale Receiving Scales Restaurant Equipment

The Ohaus® Defender® 5000 D52XW5WQS5 is a low-profile, washdown bench scale with a stainless steel frame and removable 10 in. x 10 in. weighing platform.

It features a TD52XW stainless steel indicator with IP68/NEMA 4X protection, a silicon-sealed IP67 stainless steel loadcell, legal-for-trade weighing, and multiple application modes for commercial and industrial use.

  • Capacity and readability: 10 lb. x 0.002 lb.; 160 oz. x 0.032 oz.; 5 kg. x 0.001 kg.; 5000 g. x 1 g.
  • Applications: weighing, percent weighing, piece counting with optimized APW, checkweighing, check counting, dynamic weighing, and display hold.
  • Connectivity: standard RS232 with optional Ethernet, Wi-Fi/Bluetooth, RS232/RS485/USB, analog output, and discrete I/O.

Overall Dimensions:

10.0"W x 20.8"D x 4.6"H

Product Weight:

24.3 lb

Washdown stainless steel construction

The scale has a stainless steel frame, removable stainless steel weighing platform, and silicon-sealed IP67 stainless steel loadcell.

Legal-for-trade weighing

The product is designated legal for trade and includes NTEP certification.

Protected TD52XW indicator

The stainless steel indicator has a sandblasted surface treatment and IP68/NEMA 4X protection.

Multiple application modes

Supported modes include weighing, percent weighing, piece counting with optimized APW, checkweighing, check counting, dynamic weighing, and display hold.

Dot matrix LCD display

The display uses a white LED backlight and has 256 x 80 pixels.

Connectivity options

Standard RS232 is provided, with optional Ethernet, Wi-Fi/Bluetooth, RS232/RS485/USB, analog output, and 2 in/4 out discrete I/O.

Front-mount bracket

The stainless steel front-mount bracket includes a handle.

Overload protection

The scale has a safe overload capacity of 150% of maximum capacity.

Capacity × readability 10 lb. × 0.002 lb.; 160 oz. × 0.032 oz.; 5 kg. × 0.001 kg.; 5000 g. × 1 g.
Platform size 10 in. × 10 in.
Scale type Low-profile bench scale
Construction Stainless steel frame and removable stainless steel weighing platform
Indicator TD52XW
Indicator protection IP68 / NEMA 4X
Loadcell protection Silicon-sealed IP67 stainless steel loadcell
Weighing units lb, oz, lb:oz, kg, g, metric tonnes, short ton, custom unit
Application modes Weighing, percent weighing, piece counting with optimized APW, checkweighing, check counting, dynamic weighing, display hold
Internal counting resolution 1:500,000
Maximum display resolution 1:25,000
Linearity and repeatability ±2d
Display Dot matrix LCD with white LED backlight, 256 × 80 pixels
Keyboard 6-function, 5-quick, 12-alphanumeric membrane switches
Auto-zero tracking Off, 0.5 d, 1 d, or 3 d
Zeroing range 2% or 100% of capacity
Calibration Zero, span, or 3-point linear
Safe overload capacity 150% of maximum capacity
Stabilization time Within 1 second
Operating temperature range 14°F to 104°F (-10°C to 40°C)
Interface Standard RS232; optional Ethernet, Wi-Fi/Bluetooth, RS232/RS485/USB, analog output, and 2 in/4 out discrete I/O
Power supply 100-240 VAC / 50/60 Hz universal power supply
Battery Optional rechargeable lithium battery; 20 hours of continuous use
Legal for trade Yes

Certifications & Compliance

Certified badge of CSA Certified
CSA Certified

Documents

PDF Cutsheet PDF Download

Frequently Asked Questions

Yes. The product is designated legal for trade and has NTEP certification.
It has a removable stainless steel weighing platform measuring 10 in. x 10 in.
Supported units are lb, oz, lb:oz, kg, g, metric tonnes, short ton, and custom unit.
It supports weighing, percent weighing, piece counting with optimized APW, checkweighing, check counting, dynamic weighing, and display hold.
The TD52XW indicator is rated IP68/NEMA 4X, and the silicon-sealed stainless steel loadcell is rated IP67.
The scale includes a standard RS232 interface. Optional interfaces include Ethernet, Wi-Fi/Bluetooth, RS232/RS485/USB, analog output, and 2 in/4 out discrete I/O.
