Penn Scale

Penn Scale Ohaus® D52XW50WQR6 Digital Washdown Stainless Steel Bench Receiving Scale, Legal for Trade, 100 lb x 0.02 lb, 12 x 12 in Platform

SKU: D52XW50WQR6
$2,082.78
/each
Enter ZIP for a shipping estimate
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

Related Searches

Best Sellers Commercial Food Scale Commercial Food Scales Equipment Food Prep Equipment Food Preparation Equipment New Arrivals Penn Scale Receiving Scale Receiving Scales Restaurant Equipment

The OHAUS Defender 5000 D52XW50WQR6 is a washdown bench scale with a removable 12 in × 12 in stainless steel weighing platform and TD52XW stainless steel indicator.

  • 100 lb × 0.02 lb capacity and readability
  • Legal-for-trade product data with NTEP listing
  • IP68/NEMA 4X indicator and silicon-sealed IP67 loadcell
  • Standard RS232 interface and multiple weighing application modes

Overall Dimensions:

12.0"W x 17.4"D x 23.8"H

Product Weight:

27.0 lb

Washdown construction

Includes a stainless steel platform, frame, and column, with an IP68/NEMA 4X indicator and silicon-sealed IP67 loadcell.

Capacity and readability

Measures up to 100 lb with 0.02 lb readability, or 50 kg with 10 g readability.

Legal-for-trade use

Authoritative product data identifies the scale as legal for trade and lists NTEP.

Application modes

Supports weighing, percent weighing, piece counting with optimized APW, checkweighing, checkcounting, dynamic weighing, and display hold.

Display and controls

Uses a 256 × 80 pixel dot matrix LCD with white LED backlight and a membrane keyboard with function, quick, and alphanumeric keys.

Connectivity

Includes a standard RS232 interface.

Power supply

Uses a 100–240 VAC, 50/60 Hz universal power supply.

Capacity 100 lb / 50 kg
Readability 0.02 lb / 10 g
Platform dimensions 12 in × 12 in × 3-3/4 in
Platform Removable stainless steel weighing platform
Indicator TD52XW
Indicator construction Stainless steel with sandblasted surface treatment
Indicator protection IP68 / NEMA 4X
Loadcell protection Silicon-sealed IP67
Column 13-13/16 in stainless steel
Construction Stainless steel frame
Display Dot matrix LCD with white LED backlight, 256 × 80 pixels
Weighing units lb, oz, lb:oz, kg, g, metric tonnes, short ton, custom unit
Application modes Weighing, percent weighing, piece counting with optimized APW, checkweighing/checkcounting, dynamic weighing/display hold
Internal counting resolution 1:500,000
Maximum display resolution 1:25,000
Linearity and repeatability ±2d
Safe overload capacity 150% of maximum capacity
Stabilization time Within 1 second
Operating temperature 14°F to 104°F / -10°C to 40°C
Interface Standard RS232
Power supply 100–240 VAC / 50/60 Hz
Auto-zero tracking Off, 0.5 d, 1 d, or 3 d
Zeroing range 2% or 100% of capacity
Calibration Zero, span, or 3-point linear
Legal for trade Yes

Certifications & Compliance

Certified badge of CSA Certified
CSA Certified

Documents

PDF Cutsheet PDF Download

Frequently Asked Questions

The scale has a 100 lb capacity with 0.02 lb readability, and a 50 kg capacity with 10 g readability.
The removable stainless steel weighing platform measures 12 in × 12 in and is 3-3/4 in high.
Yes. Authoritative product data identifies the D52XW50WQR6 as legal for trade and lists NTEP.
The TD52XW indicator is rated IP68/NEMA 4X, and the silicon-sealed stainless steel loadcell is rated IP67.
Supported modes include weighing, percent weighing, piece counting with optimized APW, checkweighing, checkcounting, dynamic weighing, and display hold.
The scale includes a standard RS232 interface.
The product measures 12.0 in wide × 17.4 in deep × 23.8 in high and weighs 27.0 lb.
