Penn Scale Ohaus® D52XW50RQL5 Legal-for-Trade Stainless Steel Digital Bench Scale, 100 lb x 0.02 lb, 18" x 18" Platform

SKU: D52XW50RQL5
$2,234.40
/each
Enter ZIP for a shipping estimate
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

Related Searches

Best Sellers Commercial Food Scale Commercial Food Scales Equipment Food Prep Equipment Food Preparation Equipment New Arrivals Penn Scale Receiving Scale Receiving Scales Restaurant Equipment

The Penn Scale D52XW50RQL5 is an Ohaus Defender 5000 low-profile bench scale with a 100 lb x 0.02 lb capacity and readability, an 18 x 18 inch removable stainless steel weighing platform, and a TD52XW stainless steel indicator.

  • Legal-for-trade weighing: NTEP-listed scale with CE and CSA compliance marks.
  • Multiple applications: Weighing, percent weighing, piece counting, checkweighing, check counting, dynamic weighing, and display hold.
  • Connectivity: Standard RS232 interface with optional Ethernet, Wi-Fi/Bluetooth, RS232/RS485/USB, analog output, and discrete I/O options.
  • Protection: The indicator provides IP68/NEMA 4X protection.

Overall Dimensions:

18.0"W x 28.9"D x 4.6"H

Product Weight:

39.7 lb

Legal-for-trade weighing

Identified as legal for trade and listed with NTEP certification.

Removable stainless steel platform

Includes an 18 x 18 inch removable stainless steel weighing platform.

TD52XW stainless steel indicator

The indicator has a sandblasted surface treatment and IP68/NEMA 4X protection.

Application modes

Supports weighing, percent weighing, piece counting with optimized APW, checkweighing, check counting, dynamic weighing, and display hold.

Data connectivity

Provides standard RS232 connectivity, with optional Ethernet, Wi-Fi/Bluetooth, RS232/RS485/USB, analog output, and discrete I/O.

Display and keyboard

Uses a 256 x 80 pixel dot matrix LCD with white LED backlight and a membrane keyboard with 6 function, 5 quick, and 12 alphanumeric switches.

Overload protection

Provides a safe overload capacity of 150% of maximum capacity.

Calibration and resolution

Supports zero, span, or 3-point linear calibration, with 1:500,000 internal counting resolution and 1:25,000 maximum display resolution.

Capacity x readability 100 lb x 0.02 lb; 1600 oz x 0.32 oz; 50 kg x 0.010 kg; 50,000 g x 10 g
Legal-for-trade status Legal for trade
Scale style Low-profile bench
Platform size 18 x 18 in
Platform construction Removable stainless steel
Indicator TD52XW stainless steel indicator
Indicator protection IP68/NEMA 4X
Indicator surface treatment Sandblasted
Mount Stainless steel front-mount bracket with handle
Base construction Powder-coated steel
Load cell Aluminum, silicon-sealed against moisture
Weighing units lb, oz, lb:oz, kg, g, metric tonnes, short ton, custom unit
Application modes Weighing, percent weighing, piece counting with optimized APW, checkweighing/check counting, dynamic weighing/display hold
Display Dot matrix LCD with white LED backlight, 256 x 80 pixels
Maximum display resolution 1:25,000
Internal counting resolution 1:500,000
Linearity/repeatability ±2d
Keyboard 6-function, 5-quick, 12-alphanumeric membrane switches
Auto-zero tracking Off, 0.5 d, 1 d, or 3 d
Zeroing range 2% or 100% of capacity
Calibration Zero, span, or 3-point linear
Safe overload capacity 150% of maximum capacity
Stabilization time Within 1 second
Operating temperature 14°F to 104°F (-10°C to 40°C)
Interface Standard RS232; optional Ethernet, Wi-Fi/Bluetooth, RS232/RS485/USB, analog output, and 2 in/4 out discrete I/O
Power supply 100–240 VAC, 50/60 Hz universal power supply
Battery Rechargeable lithium battery optional; 20 hours continuous use
Product dimensions 18.0 W x 28.9 D x 4.6 H in

Certifications & Compliance

Certified badge of CSA Certified
CSA Certified

Documents

PDF Cutsheet PDF Download

Frequently Asked Questions

The scale has a 100 lb x 0.02 lb capacity and readability, equivalent to 50 kg x 10 g.
It has an 18 x 18 inch removable stainless steel weighing platform.
Yes. The product is identified as legal for trade and is listed with NTEP certification.
It supports weighing, percent weighing, piece counting with optimized APW, checkweighing, check counting, dynamic weighing, and display hold.
Standard RS232 is provided. Optional interfaces include Ethernet, Wi-Fi/Bluetooth, RS232/RS485/USB, analog output, and 2-in/4-out discrete I/O.
It uses a 100–240 VAC, 50/60 Hz universal power supply. A rechargeable lithium battery is optional.
The listed product dimensions are 18.0 inches wide, 28.9 inches deep, and 4.6 inches high.
