Penn Scale

Penn Scale Ohaus® D52XW2WQS6 Legal-for-Trade Washdown Stainless Steel Digital Bench Receiving Scale, 5 lb x 0.001 lb

SKU: D52XW2WQS6
$1,925.58
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

The Penn Scale Ohaus Defender 5000 D52XW2WQS6 is a legal-for-trade washdown bench scale with a stainless steel construction, 5 lb capacity, and 0.001 lb readability.

  • Platform: 10 x 10 in removable stainless steel weighing platform.
  • Indicator: TD52XW stainless steel indicator with IP68/NEMA 4X protection.
  • Load cell: Silicon-sealed IP67 stainless steel loadcell.
  • Functions: Weighing, percent weighing, piece counting, checkweighing, checkcounting, dynamic weighing, and display hold.
  • Connectivity: Standard RS232 interface with optional Ethernet, Wi-Fi/Bluetooth, RS232/RS485/USB, analog output, and discrete I/O options.

Overall Dimensions:

10.0"W x 15.1"D x 23.6"H

Product Weight:

24.0 lb

Washdown stainless steel construction

Includes a removable stainless steel weighing platform, stainless steel frame and column, IP68/NEMA 4X indicator, and IP67 loadcell.

Legal-for-trade weighing

Specified for legal-for-trade applications and listed with NTEP compliance.

Multiple weighing units

Supports lb, oz, lb:oz, kg, g, metric tonnes, short ton, and custom unit settings.

Application modes

Provides weighing, percent weighing, piece counting with optimized APW, checkweighing, checkcounting, dynamic weighing, and display hold.

Backlit display and membrane keyboard

Uses a 256 x 80 pixel dot matrix LCD with white LED backlight and a membrane keyboard with function, quick, and alphanumeric switches.

Connectivity options

Includes standard RS232 and supports optional Ethernet, Wi-Fi/Bluetooth, RS232/RS485/USB, analog output, and 2-in/4-out discrete I/O interfaces.

Adjustable calibration

Supports zero, span, or 3-point linear calibration.

Overload protection

Safe overload capacity is specified at 150% of maximum capacity.

Related Searches

Best Sellers Commercial Food Scale Commercial Food Scales Equipment Food Prep Equipment Food Preparation Equipment New Arrivals Penn Scale Receiving Scale Receiving Scales Restaurant Equipment
Capacity 5 lb / 80 oz / 2.5 kg / 2500 g
Readability 0.001 lb / 0.016 oz / 0.0005 kg / 0.5 g
Platform size 10 x 10 in
Platform construction Removable stainless steel weighing platform
Frame construction Stainless steel
Indicator TD52XW stainless steel indicator
Indicator protection IP68 / NEMA 4X
Loadcell Silicon-sealed IP67 stainless steel loadcell
Display Dot matrix LCD with white LED backlight, 256 x 80 pixels
Maximum display resolution 1:25,000
Internal counting resolution 1:500,000
Linearity and repeatability ±2d
Application modes Weighing, percent weighing, piece counting with optimized APW, checkweighing, checkcounting, dynamic weighing, and display hold
Keyboard 6-function, 5-quick, 12-alphanumeric membrane switches
Auto-zero tracking Off, 0.5d, 1d, or 3d
Zeroing range 2% or 100% of capacity
Safe overload capacity 150% of maximum capacity
Stabilization time Within 1 second
Operating temperature 14°F to 104°F (-10°C to 40°C)
Power supply 100-240 VAC, 50/60 Hz universal power supply
Battery Optional rechargeable lithium battery
Battery life 20 hours of continuous use
Interface Standard RS232; optional Ethernet, Wi-Fi/Bluetooth, RS232/RS485/USB, analog output, and 2-in/4-out discrete I/O

Certifications & Compliance

Certified badge of CSA Certified
CSA Certified

Documents

PDF Cutsheet PDF Download

Frequently Asked Questions

The scale has a 5 lb capacity with 0.001 lb readability. Equivalent specifications are 80 oz x 0.016 oz, 2.5 kg x 0.0005 kg, and 2500 g x 0.5 g.
The removable stainless steel weighing platform measures 10 x 10 in.
Yes. The product is specified for legal-for-trade use and has NTEP compliance.
The TD52XW indicator is rated IP68/NEMA 4X, and the stainless steel loadcell is silicon-sealed with IP67 protection.
Available modes include weighing, percent weighing, piece counting with optimized APW, checkweighing, checkcounting, dynamic weighing, and display hold.
Standard RS232 is included. Ethernet, Wi-Fi/Bluetooth, RS232/RS485/USB, analog output, and 2-in/4-out discrete I/O are optional interfaces.
The specified operating temperature range is 14°F to 104°F (-10°C to 40°C).
A rechargeable lithium battery is specified as optional; the standard power supply is 100-240 VAC at 50/60 Hz.
