Penn Scale Ohaus® D52XW12RQR1 Legal-for-Trade Digital Stainless Steel Bench Scale, 25 lb Capacity, 12" x 12" Platform

SKU: D52XW12RQR1
$1,972.66
/each
Enter ZIP for a shipping estimate
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

Related Searches

Best Sellers Commercial Food Scale Commercial Food Scales Equipment Food Prep Equipment Food Preparation Equipment New Arrivals Penn Scale Receiving Scale Receiving Scales Restaurant Equipment

The Penn Scale D52XW12RQR1 is an Ohaus Defender 5000 bench scale with a 25 lb capacity and a removable 12 in x 12 in stainless steel weighing platform. Its TD52XW stainless steel indicator has IP68/NEMA 4X protection.

  • Certified readability of 0.005 lb, 0.05 oz, 0.002 kg, or 2 g.
  • Supports weighing, percent weighing, piece counting with optimized APW, checkweighing and checkcounting, and dynamic weighing or display hold.
  • Features a dot matrix LCD with white LED backlight and a 256 x 80 pixel display.
  • Includes a standard RS232 interface, with additional interfaces available as options.
  • Listed certifications include NTEP, CE, and CSA.

Overall Dimensions:

12.0"W x 17.4"D x 23.8"H

Product Weight:

26.5 lb

Legal-for-trade weighing

The product is identified for legal-for-trade use and has NTEP certification listed.

Stainless steel weighing platform

The removable platform measures 12 in x 12 in x 3-3/4 in.

Protected stainless steel indicator

The TD52XW indicator has a sandblasted stainless steel surface treatment and IP68/NEMA 4X protection.

Multiple application modes

Supports weighing, percent weighing, piece counting with optimized APW, checkweighing/checkcounting, and dynamic weighing/display hold.

Data connectivity

A standard RS232 interface is included; Ethernet, Wi-Fi/Bluetooth, RS232/RS485/USB, analog output, and discrete I/O are optional.

Calibration controls

Supports zero, span, and 3-point linear calibration.

Overload protection

Safe overload capacity is 150% of maximum capacity.

Scale type Bench
Capacity 25 lb / 400 oz / 12.5 kg / 12,500 g
Default readability 0.001 lb / 0.5 g
Certified readability 0.005 lb / 0.05 oz / 0.002 kg / 2 g
Platform size 12 in x 12 in
Platform construction Stainless steel, removable; 3-3/4 in height
Indicator TD52XW stainless steel
Indicator protection IP68 / NEMA 4X
Column 13-13/16 in powder-coated steel
Base construction Powder-coated steel
Load cell Aluminum, silicon sealed against moisture
Weighing units lb, oz, lb:oz, kg, g, metric tonnes, short ton, custom unit
Application modes Weighing, percent weighing, piece counting with optimized APW, checkweighing/checkcounting, dynamic weighing/display hold
Display Dot matrix LCD with white LED backlight, 256 x 80 pixels
Maximum display resolution 1:25,000
Internal counting resolution 1:500,000
Linearity/repeatability ±2d
Keyboard 6-function, 5-quick, 12-alphanumeric membrane switches
Auto-zero tracking Off, 0.5 d, 1 d, or 3 d
Zeroing range 2% or 100% of capacity
Calibration Zero, span, or 3-point linear
Safe overload capacity 150% of maximum capacity
Stabilization time Within 1 second
Operating temperature range 14°F to 104°F / -10°C to 40°C
Interface Standard RS232; optional Ethernet, Wi-Fi/Bluetooth, RS232/RS485/USB, analog output, and 2-in/4-out discrete I/O
Power supply 100-240 V AC, 50/60 Hz universal power supply
Battery Optional rechargeable lithium battery; 20 hours continuous use
Construction Stainless steel platform, powder-coated steel base, aluminum load cell

Certifications & Compliance

Certified badge of CSA Certified
CSA Certified

Documents

PDF Cutsheet PDF Download

Frequently Asked Questions

The scale has a 25 lb capacity and certified readability of 0.005 lb, 0.05 oz, 0.002 kg, or 2 g.
It has a removable 12 in x 12 in stainless steel weighing platform.
Supported modes include weighing, percent weighing, piece counting with optimized APW, checkweighing/checkcounting, and dynamic weighing/display hold.
The TD52XW stainless steel indicator is rated IP68/NEMA 4X.
A standard RS232 interface is included. Ethernet, Wi-Fi/Bluetooth, RS232/RS485/USB, analog output, and discrete I/O are optional.
