Penn Scale Ohaus® D52P125RQV3 Legal-for-Trade Digital Bench Scale, Stainless Steel, 250 lb x 0.05 lb, 24" x 24" Platform

SKU: D52P125RQV3
$2,615.05
/each
Enter ZIP for a shipping estimate
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

Related Searches

Best Sellers Commercial Food Scale Commercial Food Scales Equipment Food Prep Equipment Food Preparation Equipment New Arrivals Penn Scale Receiving Scale Receiving Scales Restaurant Equipment

The Ohaus® Defender® 5000 D52P125RQV3 is a bench-style digital scale with a 250 lb capacity, 0.05 lb certified readability, and a 24 × 24 in stainless steel removable weighing platform.

The TD52P ABS indicator supports weighing, percent weighing, piece counting with optimized APW, checkweighing and checkcounting, and dynamic weighing with display hold. The counting function is not legal for trade.

  • Indicator: Dot matrix LCD with white LED backlight and a 6-function, 5-quick, 12-alphanumeric membrane keyboard.
  • Connectivity: Standard RS232 interface with optional Ethernet, WiFi/Bluetooth, RS232/RS485/USB, analog output, and discrete I/O.
  • Construction: Stainless steel removable platform, powder-coated steel base and column, and an aluminum load cell sealed against moisture with silicone.
  • Protection: Safe overload capacity is 150% of maximum capacity, with stabilization within 1 second.

Overall Dimensions:

24.0"W x 30.4"D x 47.4"H

Product Weight:

92.6 lb

Certified weighing

Capacity × certified readability is 250 lb × 0.05 lb, or 125 kg × 20 g. NTEP is specified for the scale; the counting function is not legal for trade.

Application modes

Supports weighing, percent weighing, piece counting with optimized APW, checkweighing/checkcounting, and dynamic weighing/display hold.

TD52P indicator

The ABS indicator uses a dot matrix LCD with white LED backlight, 256 × 80 pixels, and a membrane keyboard with 6 function, 5 quick, and 12 alphanumeric switches.

Connectivity

Includes a standard RS232 interface. Optional interfaces include Ethernet, WiFi/Bluetooth, RS232/RS485/USB, analog output, and 2-in/4-out discrete I/O.

Platform and base construction

The scale has a stainless steel removable weighing platform and a powder-coated steel base.

Moisture-sealed load cell

The aluminum load cell is silicon sealed against moisture.

Overload protection

Safe overload capacity is 150% of maximum capacity.

Calibration and zeroing

Supports zero, span, or 3-point linear calibration, with selectable auto-zero tracking and a zeroing range of 2% or 100% of capacity.

Capacity 250 lb / 125 kg
Certified readability 0.05 lb / 0.020 kg / 20 g
Platform size 24 × 24 in
Platform material Stainless steel
Platform type Removable weighing platform
Column height 38-5/8 in
Indicator TD52P ABS
Base construction Powder-coated steel
Load cell Aluminum, silicon sealed against moisture
Weighing units lb, oz, lb:oz, kg, g, metric tonnes, short ton, custom unit
Application modes Weighing, percent weighing, piece counting with optimized APW, checkweighing/checkcounting, dynamic weighing/display hold
Display Dot matrix LCD with white LED backlight, 256 × 80 pixels
Maximum display resolution 1:25,000
Internal counting resolution 1:500,000
Linearity/repeatability ±2d
Safe overload capacity 150% of maximum capacity
Stabilization time Within 1 second
Operating temperature range 14°F to 104°F (-10°C to 40°C)
Keyboard 6-function, 5-quick, 12-alphanumeric membrane switches
Interface Standard RS232; optional Ethernet, WiFi/Bluetooth, RS232/RS485/USB, analog output, and 2-in/4-out discrete I/O
Power supply 100-240 VAC, 50/60 Hz universal power supply
Battery Optional rechargeable lithium battery; 20 hours continuous use
Calibration Zero, span, or 3-point linear
Approximate net weight 86 lb
Legal-for-trade status NTEP; counting function is not legal for trade

Certifications & Compliance

Certified badge of CSA Certified
CSA Certified

Documents

PDF Cutsheet PDF Download

Frequently Asked Questions

The scale has a 250 lb capacity with 0.05 lb certified readability, equivalent to 125 kg × 20 g.
The removable weighing platform measures 24 × 24 in and is stainless steel.
It uses a TD52P ABS indicator with a dot matrix LCD and white LED backlight.
Available modes include weighing, percent weighing, piece counting with optimized APW, checkweighing/checkcounting, and dynamic weighing/display hold.
No. The counting function is not legal for trade.
RS232 is standard. Ethernet, WiFi/Bluetooth, RS232/RS485/USB, analog output, and 2-in/4-out discrete I/O are optional interfaces.
The operating temperature range is 14°F to 104°F, or -10°C to 40°C.
