Oscartek Rosa ROSA RMA90SQ Refrigerated Red Meat 90° Square Corner Showcase, 51" x 51", Extra-Clear Glass, LED Lighting

SKU: ROSA RMA90SQ
$25,087.00

Want to speak to an expert?

ROSA RMA90SQ is a refrigerated red meat showcase with a 90° square-corner configuration, extra-clear front and top glass, and a front air baffle.

  • Diffused 3000 K LED lighting and heated glass sides support product presentation.
  • Sliding acrylic back doors provide operator-side access.
  • The case includes a stainless steel lower interior foam tub, galvanized chassis structure, and all tempered glass.
  • Fan-ventilated, self-contained refrigeration has a documented operating temperature of 38°F to 41°F.

The case ships standard with an unfinished front and stainless steel sides.

Overall Dimensions:

51.25"W x 32.31"D x 47.25"H

Product Weight:

990.0 lb

90° square-corner configuration

Configured as a 90° square corner showcase for red meat display.

Extra-clear glass

Uses extra-clear front and top glass with a front air baffle.

Heated glass sides

The side glass is heated.

Diffused LED lighting

Includes diffused LED lighting at 3000 K.

Sliding acrylic back doors

Sliding acrylic doors are provided on the back of the case.

Interior and chassis construction

Includes a stainless steel lower interior foam tub and galvanized chassis structure.

Refrigeration

Fan-ventilated, self-contained refrigeration serves a deck display area with a documented operating temperature of 38°F to 41°F.

Tempered glass

All glass is tempered.

Product type Refrigerated red meat showcase
Configuration 90° square corner
Glass Extra-clear front and top glass; all tempered glass
Front air baffle Included
Side glass Heated
Lighting Diffused LED, 3000 K
Back doors Sliding acrylic
Lower interior Stainless steel foam tub
Chassis Galvanized structure
Refrigeration Fan ventilated; self-contained
Display area Deck
Operating temperature 38°F to 41°F
Compressor 1 / hermetic
Refrigerant gas R404A / R452A
Electrical supply 115 V / 1 ph / 60 Hz
Power consumption 1500 W / 14.2 A
Defrost Automatic
Climatic class 75°F / 55% RH
BTU at +14°F evaporator temperature 4800 BTU
Pipe size 5/8 in suction; 5/16 in liquid
Exterior finish Standard unfinished front and stainless steel sides
Net weight 380 lb
Shipping dimensions 70 in L x 70 in D x 70 in H
Weight 990 lb
Dimension note Dimensions with polished stainless steel sides

Certifications & Compliance

Certified badge of ETL Listed
ETL Listed

Frequently Asked Questions

It is a refrigerated red meat showcase with a 90° square-corner configuration and deck display area.
The documented operating temperature is 38°F to 41°F.
It uses 115 V, 1-phase, 60 Hz electrical service and is listed at 1500 W and 14.2 A.
It has extra-clear front and top glass, heated glass sides, all tempered glass, and sliding acrylic back doors.
