Oscartek Rosa ROSA FA90C Refrigerated Fish Display Case, 78", 90° Curved Glass, Stainless Steel Interior, LED Lighting

SKU: ROSA FA90C
$25,069.33
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

ROSA FA90C is a 90° curved refrigerated fish showcase with a 78.13-inch width, extra-clear tempered glass on the front, top, and sides, and diffused 3000 K LED lighting.

The case features self-contained refrigeration, cold-wall static cooling, and an insulated stainless steel bin to retain ice. Its insulated AISI 316 stainless steel interior provides anti-corrosion construction, while sliding acrylic back doors support access.

Standard cases ship with an unfinished front and stainless steel sides. A floor sink is required.

Overall Dimensions:

78.13"W x 32.31"D x 47.25"H

Product Weight:

990.0 lb

90° curved showcase

Open curved configuration for refrigerated fish presentation.

Tempered glass

Extra-clear tempered glass is used on the front, top, and sides.

Diffused LED lighting

Integrated lighting is rated at 3000 K.

Cold-wall static cooling

The insulated stainless steel bin is designed to retain ice.

AISI 316 stainless steel interior

Insulated interior construction with anti-corrosion properties.

Sliding acrylic back doors

Acrylic doors are located at the back of the case.

Standard case finish

Standard cases ship with an unfinished front and stainless steel sides.

Drainage requirement

A floor sink is required.

Related Searches

Best Sellers Display Refrigeration Food Displays & Merchandisers New Arrivals Oscartek Refrigerated Deli, Bakery & Sushi Cases Refrigerated Display Case Equipment Refrigerated Display Cases Refrigeration & Ice Restaurant Equipment
Display type 90° curved refrigerated fish showcase
Refrigeration Self-contained refrigeration
Operating temperature 36°F to 40°F
Compressor 1 hermetic compressor
Refrigerant R404A / R452A
Cooling method Cold-wall static cooling
Lighting Diffused LED, 3000 K
Glass Extra-clear tempered glass, front, top, and sides
Back doors Sliding acrylic
Interior finish Insulated AISI 316 stainless steel, anti-corrosion
Electrical supply 115 V / 1-phase / 60 Hz
Power consumption 1500 W / 14.2 A
Refrigeration capacity 5400 BTU at -3°F evaporator temperature
Climatic class 75°F / 55% RH
Pipe size 1/2 in. suction, 1/4 in. liquid
Net weight 380 lb
Weight 990 lb
Standard front finish Unfinished front
Standard side finish Stainless steel sides

Certifications & Compliance

Certified badge of ETL Listed
ETL Listed

Documents

PDF Cutsheet PDF Download

Frequently Asked Questions

The product measures 78.13 in. wide, 32.31 in. deep, and 47.25 in. high.
The operating temperature is 36°F to 40°F.
The case uses 115 V, 1-phase, 60 Hz electrical service and consumes 1500 W at 14.2 A.
It uses self-contained refrigeration with one hermetic compressor, cold-wall static cooling, and R404A/R452A refrigerant.
It includes diffused LED lighting rated at 3000 K.
The case has sliding acrylic back doors.
Yes. A floor sink is required.
The net weight is 380 lb, and the shipping weight is 990 lb.
