Oscartek Rosa ROSA CCA90SQ Cheese & Charcuterie Deli Display Case, 90° Square Corner, Straight Glass, Self-Contained Refrigeration, 51"

SKU: ROSA CCA90SQ
$23,865.97

Want to speak to an expert?

The Oscartek ROSA CCA90SQ is a 90° square-corner cheese and charcuterie showcase with a straight-glass front and self-contained refrigeration.

  • Extra-clear front and top glass with a front air baffle
  • Heated glass sides and all-tempered-glass construction
  • Diffused 3000 K LED lighting
  • Sliding acrylic back doors
  • Stainless steel lower interior foam tub and galvanized chassis structure
  • Standard unfinished front with stainless steel skin sides

Overall Dimensions:

51.25"W x 32.31"D x 47.25"H

Product Weight:

990.0 lb

90° square-corner design

Configured as a 90° square-corner cheese and charcuterie showcase.

Straight extra-clear glass

The front and top use extra-clear glass, with a front air baffle.

Heated glass sides

Heated glass sides help define the display enclosure.

Diffused LED lighting

Integrated diffused LED lighting is rated at 3000 K.

Sliding acrylic back doors

Sliding acrylic doors provide operator-side access.

Self-contained refrigeration

The case uses self-contained, fan-ventilated refrigeration with automatic defrost and a 38°F to 41°F operating range.

Stainless steel lower interior

The lower interior includes a stainless steel foam tub.

Galvanized chassis

The case uses a galvanized chassis structure.

Standard exterior finish

The standard case has an unfinished front and stainless steel skin sides.

Case configuration 90° square corner
Front glass Straight glass
Refrigeration Self-contained, fan-ventilated
Display area Deck
Service type Full service
Shelf configuration Deck only
Operating temperature 38°F to 41°F
Compressor 1 / hermetic
Defrost Automatic
Refrigerant R404A / R452A
Cooling capacity 4800 BTU at +14°F evaporator temperature
Electrical supply 115 V / 1 ph / 60 Hz
Power consumption 1500 W / 14.2 A
Refrigerant pipe size 5/8 in suction, 5/16 in liquid
Lighting Diffused LED, 3000 K
Back doors Sliding acrylic
Interior construction Stainless steel lower interior foam tub
Chassis construction Galvanized
Standard exterior Unfinished front with stainless steel skin sides
Net weight 380 lb
Weight 990 lb

Certifications & Compliance

Certified badge of ETL Listed
ETL Listed

Frequently Asked Questions

The case measures 51.25 in wide, 32.31 in deep, and 47.25 in high.
Yes. The ROSA CCA90SQ has self-contained, fan-ventilated refrigeration.
The listed operating temperature is 38°F to 41°F.
It uses 115 V, single-phase, 60 Hz power and is rated at 1500 W and 14.2 A.
It has straight extra-clear front and top glass, heated glass sides, and all-tempered-glass construction.
Operator-side access is provided by sliding acrylic back doors.
