Oscartek Rosa ROSA CA90SQ Refrigerated Chocolate Display Case, 90° Square Corner, Extra-Clear Tempered Glass, Humidity Control
SKU: ROSA CA90SQ
$26,359.82
The Oscartek ROSA CA90SQ is a refrigerated 90° square-corner chocolate showcase with humidity control and self-contained refrigeration.
- Extra-clear tempered glass on the front, top, and sides with a front air baffle.
- Diffused 3000 K LED lighting and sliding acrylic back doors.
- Stainless steel lower interior foam tub and galvanized chassis structure.
- Standard unfinished front with stainless steel skin sides.
Overall Dimensions:
51.25"W x 32.31"D x 47.25"HProduct Weight:
990.0 lbHumidity control
Maintains the specified 55% RH to 65% RH relative humidity range.
Extra-clear tempered glass
Front, top, and side glass panels are extra-clear and tempered, with a front air baffle.
Diffused LED lighting
Provides diffused illumination at 3000 K.
Sliding acrylic back doors
Rear access is provided by sliding acrylic doors.
Self-contained refrigeration
The case uses self-contained, fan-ventilated refrigeration with a 55°F to 60°F operating range.
Interior and chassis construction
Includes a stainless steel lower interior foam tub and galvanized chassis structure.
Standard exterior finish
Ships with an unfinished front and stainless steel skin sides.
Configuration
90° square corner
Display type
Chocolate showcase/display
Glass
Extra-clear tempered glass; front, top, and sides
Front air baffle
Included
Lighting
Diffused LED, 3000 K
Back doors
Sliding acrylic
Lower interior
Stainless steel foam tub
Chassis
Galvanized structure
Refrigeration
Self-contained; fan ventilated
Display area
Deck
Operating temperature
55°F to 60°F
Relative humidity
55% RH to 65% RH
Compressor
1 / hermetic
Cooling capacity at +35°F evaporator temperature
3900 BTU
Electrical supply
208–220 V / 1 ph / 60 Hz
Power consumption
1150 W / 10.9 A
Defrost
Automatic
Climatic class
75°F / 55% RH
Refrigerant
R404A / R452A
Pipe size
1/2 in suction; 1/4 in liquid
Net weight
410 lb
Crated weight
990 lb
Ends
Mirrored
Front
Straight glass
Certifications & Compliance
Documents
Frequently Asked Questions
The external dimensions are 51.25 in wide, 32.31 in deep, and 47.25 in high.
It requires 208–220 V, single-phase, 60 Hz service and is rated at 1150 W and 10.9 A.
The operating temperature is 55°F to 60°F, and the specified relative humidity range is 55% RH to 65% RH.
It uses extra-clear tempered glass on the front, top, and sides, with a front air baffle.
Yes. Humidity control is a standard feature.
The case has sliding acrylic back doors.
The specified refrigerant is R404A / R452A.
