Oscartek Muro MURO H12-1 1800 71-Inch Self-Serve Air Screen Refrigerated Merchandiser, Self-Contained Bottom-Mount

SKU: MURO H12-1 1800
$17,973.00
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

MURO H12-1 1800 is a 71-inch self-serve air screen refrigeration merchandiser with self-contained bottom-mount refrigeration.

It includes one straight or inclined shelf, diffused 3000 K LED lighting, double-pane side glass ends, a Dixell digital control, adjustable feet, and a roll-down night curtain.

The standard case has a polished stainless steel A304 interior and exterior. A floor sink is recommended for the self-contained configuration.

Electrical service is 208-220 V, single-phase, 60 Hz, with 8.0 A listed.

Overall Dimensions:

71.0"W x 34.5"D x 47.25"H

Product Weight:

510.0 lb

Self-contained bottom-mount refrigeration

The refrigeration system is self-contained and configured as a bottom mount; a floor sink is recommended.

Single shelf

The H12-1 configuration has one straight or inclined shelf.

Diffused LED lighting

Diffused LED lighting is rated at 3000 K.

Double-pane side glass ends

Dixell digital control

Polished stainless steel A304 construction

The standard interior and exterior are polished stainless steel A304.

Roll-down night curtain

Adjustable feet

Related Searches

Best Sellers Display Refrigeration General Refrigerated Display Cases New Arrivals Oscartek Refrigerated Display Case Equipment Refrigeration & Ice
Product Type Self-serve air screen refrigeration merchandiser/showcase/display
Overall Length 71 in
Refrigeration Configuration Self-contained bottom-mount (BM)
Shelf Configuration (1) straight or inclined shelf
Lighting Diffused LED, 3000 K
Side Glass Double-pane side glass ends
Controller Dixell digital control
Interior and Exterior Polished stainless steel A304
Night Curtain Roll-down
Operating Temperature 40°F
Electrical Supply 208-220 V / 1 Ph / 60 Hz
Power Consumption 1600 W / 8.0 A
Refrigerant R404A / R452A
Pipe Size 5/8 in suction, 5/16 in liquid
Climate Class 75°F / 55% RH
BTU at +14°F Evaporator Temperature 7,500 BTU; actual BTU may vary
Weight 510 lb

Certifications & Compliance

Certified badge of ETL Listed
ETL Listed

Documents

PDF Cutsheet PDF Download

Frequently Asked Questions

The product measures 71 in wide by 34.5 in deep by 47.25 in high.
It uses self-contained bottom-mount refrigeration. A floor sink is recommended.
The H12-1 configuration has one straight or inclined shelf.
The listed electrical supply is 208-220 V, single-phase, 60 Hz, with 8.0 A listed.
It has diffused LED lighting rated at 3000 K.
The listed certifications are CE, ETL-Sanitation, and cETLus.
The listed operating temperature is 40°F.
