Oscartek Italia 1-2-3 ITALIA 3 C 90SQL Multi-Level Refrigerated Display Case for Chocolate/Macarons, Humidity Control, 78-7/8"W

SKU: ITALIA 3 C 90SQL
$33,948.88
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

Oscartek ITALIA 3 C 90SQL is a multi-level refrigerated display case for chocolate and macarons applications, with ventilated refrigeration and humidity control.

  • Maintains a temperature range of 57°F to 65°F (14°C to 18°C) and relative humidity of 50–55%.
  • Includes three height-adjustable glass shelves with LED lighting on an electrified rack.
  • Features double-paned front, side and top glass, plus rear double-paned sliding and hinged doors.
  • Uses dimmable diffused LED lighting at 3000 K and a self-contained condensing unit with R290 refrigerant.
  • Includes electronic temperature control with digital display, programmed automatic defrost and a condensate evaporator pan.

The case has a stainless-steel AISI 304 structure, polished stainless-steel interior finishes, a fully insulated stainless-steel tub, an unfinished front and included stainless-steel side panels.

Overall Dimensions:

78.88"W x 59.13"D x 53.13"H

Product Weight:

1367.0 lb

Humidity-controlled refrigeration

Ventilated refrigeration maintains a 57°F to 65°F (14°C to 18°C) temperature range with 50–55% relative humidity.

Adjustable glass shelving

Includes three height-adjustable glass shelves with LED lighting on an electrified rack.

Double-paned glazing

The front, sides and top use double-paned glass; rear access includes two double-paned sliding doors and one hinged door.

LED illumination

Dimmable diffused LED lighting operates at 3000 K.

Self-contained condensing unit

The case uses a self-contained condensing unit with R290 refrigerant and a back-to-front breathing configuration.

Electronic controls

Electronic temperature control includes a digital display and programmed automatic defrost.

Stainless-steel construction

Features standard stainless-steel AISI 304, polished stainless-steel interior finishes and a fully insulated stainless-steel tub.

Rear door closure

The rear hinged door and sliding doors have a self-closing system.

Adjustable support

The steel chassis includes height-adjustable feet.

Related Searches

Best Sellers Display Case, Chocolate Display Refrigeration Disposable Dishes Disposable Tableware Disposables & Consumables New Arrivals Oscartek Refrigerated Display Case Equipment Refrigeration & Ice
Product type Multi-level refrigerated display case
Applications Chocolate and macarons
Refrigeration type Ventilated, self-contained refrigeration
Temperature range 57°F to 65°F (14°C to 18°C)
Relative humidity 50–55%
Refrigerant R290
Breathing configuration Back-to-front
Front glass Double-paned straight glass with RAL-9005 jet black serigraphy
Side and top glass Double-paned glass with RAL-9005 jet black serigraphy
Rear access 2 double-paned glass sliding doors and 1 hinged door with self-closing system
Shelf quantity 3
Shelf type Height-adjustable glass shelves
Lighting Dimmable diffused LED, 3000 K
Glass construction Tempered glass
Tub construction Fully insulated stainless steel
Interior finish Polished stainless steel
Material Stainless steel AISI 304
Front finish Unfinished
Side panels Stainless-steel side panels included
Temperature control Electronic control with digital display
Defrost Programmed automatic defrost
Condensate management Condensate evaporator pan included
Electrical supply 208–220 V / 60 Hz / 1 phase
Current draw 15.9 A
Power connection 6-foot pigtail cord with NEMA 5-20P
Chassis Steel chassis with height-adjustable feet
Shipping dimensions 79 in W x 60 in D x 54 in H
Weight 1367 lb

Certifications & Compliance

Certified badge of ETL Listed
ETL Listed

Documents

PDF Cutsheet PDF Download

Frequently Asked Questions

It is a multi-level refrigerated display case for chocolate and macarons applications.
The temperature range is 57°F to 65°F (14°C to 18°C), with relative humidity of 50–55%.
The case includes three height-adjustable glass shelves with LED lighting on an electrified rack.
It uses ventilated refrigeration with a self-contained condensing unit and R290 refrigerant.
The case requires 208–220 V, 60 Hz, single-phase power and draws 15.9 A. It includes a 6-foot pigtail cord with a NEMA 5-20P plug.
The product measures 78-7/8 in wide by 59-1/8 in deep by 53-1/8 in high.
Rear access includes two double-paned glass sliding doors and one hinged door, all with RAL-9005 jet black serigraphy; the doors have a self-closing system.
