Oscartek Classic II CLASSIC II CIIDPCA90 Refrigerated Curved Full-Service Deli/Pastry/Chocolate Display Case, Stainless Interior, 80.9" Wide

SKU: CLASSIC II CIIDPCA90
$18,877.32

Want to speak to an expert?

The CLASSIC II CIIDPCA90 is a refrigerated 90° curved open display case for deli, pastry, and chocolate service.

  • Stainless steel insulated body with a tubular painted galvanized chassis.
  • High-polish 304 stainless steel interior and stainless steel work top.
  • Self-contained refrigeration with an air-cooled condensing unit and Dixell digital controller.
  • Single-pane front and side glass with anti-fog serigraph, curved tilt-back tempered front glass, and plexiglass sliding doors.
  • Diffused LED lighting rated at 3000K.
  • Humidity-controlled deck with one shelf.

Overall Dimensions:

80.9"W x 34.17"D x 51.1"H

Product Weight:

318.0 lb

90° curved configuration

Open 90° curved design for deli, pastry, and chocolate showcase service.

Full-service design

Configured as a full-service refrigerated display case.

Stainless steel construction

Stainless steel insulated body with a tubular painted galvanized chassis.

304 stainless steel interior

High-polish 304 stainless steel interior.

Self-contained refrigeration

Uses self-contained refrigeration with an air-cooled condensing unit.

Digital temperature control

Equipped with a Dixell digital controller.

Glass and access

Single-pane front and side glass with anti-fog serigraph, curved tilt-back tempered front glass, and plexiglass sliding doors.

LED lighting

Diffused LED lighting rated at 3000K.

Humidity-controlled deck

The deck is humidity controlled and the case has one shelf.

Stainless steel work top

Includes a stainless steel work top.

Case type Refrigerated display case/showcase
Service type Full service
Application Deli, pastry, and chocolate showcase/display
Configuration 90° curved open
Exterior finish Specify exterior; case ships standard unfinished
Body construction Stainless steel insulated body with tubular painted galvanized chassis
Interior finish High-polish 304 stainless steel
Refrigeration Self-contained refrigeration
Condensing unit Air cooled
Controller Dixell digital controller
Deck control Humidity controlled on deck
Deck operating temperature 39°F
Shelf quantity 1 shelf
Front and side glass Single pane with anti-fog serigraph
Front glass Curved tilt-back tempered glass
Access doors Plexiglass sliding doors
Lighting Diffused LED, 3000K
Work top Stainless steel
Electrical supply Chocolate: 208–220 V / 60 Hz / 1 ph; deli/pastry: 120 V / 60 Hz / 1 ph
Current 5.5 A

Certifications & Compliance

Certified badge of ETL Listed
ETL Listed

Frequently Asked Questions

The case measures 80.9 in wide, 34.17 in deep, and 51.1 in high.
It uses self-contained refrigeration with an air-cooled condensing unit and a Dixell digital controller.
The specified configuration is 208–220 V / 60 Hz / 1 ph for chocolate, and 120 V / 60 Hz / 1 ph for deli and pastry.
The interior is high-polish 304 stainless steel.
The authoritative category attributes specify one shelf.
The listed certifications are CE, ETL-Sanitation, and cETLus.
