Mr. Espresso Faema FAEMA X20 CS - SINGLE STEP SOLUBLE 1-Group Super Automatic Espresso Machine with Single-Step Soluble System

SKU: FAEMA X20 CS - SINGLE STEP SOLUBLE
$21,600.00

Want to speak to an expert?

The FAEMA X20 CS - SINGLE STEP SOLUBLE is a 1-group super-automatic espresso machine with single-step soluble operation, a precision milk delivery system, and a 7-inch touchscreen interface.

  • Supports up to 48 individual customizable drinks.
  • Includes two titanium burr grinders, two bean hoppers, and one soluble hopper and mixer.
  • Features a 2.6-liter boiler with Smart Boiler technology and a 250 ml heat exchanger.
  • Provides automatic coffee, milk, and soluble circuit wash cycles.
  • Includes bidirectional WiFi connectivity with remote monitoring and a USB programming port.

The machine has a high-polish stainless steel work surface and black powder-coated steel construction.

Overall Dimensions:

14.6"W x 24.4"D x 30.0"H

Product Weight:

157.0 lb

Single-step soluble system

Includes one soluble hopper and mixer for single-step soluble operation.

Customizable touchscreen interface

A 7-inch touchscreen interface provides a customizable display and supports up to 48 individual customizable drinks.

Titanium burr grinders

Includes two titanium burr grinders.

Smart Boiler technology

Uses a 2.6-liter boiler with Smart Boiler technology and a 250 ml heat exchanger.

Precision milk delivery

Includes a precision milk delivery system and one manual steam arm.

Automatic wash cycles

Provides automatic coffee, milk, and soluble circuit wash cycles.

Connectivity and programming

Includes bidirectional WiFi connectivity with remote monitoring capabilities and a USB programming port.

Commercial construction

Features a high-polish stainless steel work surface and black powder-coated steel construction.

Machine type Super-automatic espresso machine
Group heads 1 group
Operation Super automatic
Soluble operation Single step
Boiler capacity 2.6 L
Heat exchanger capacity 250 ml
Bean hoppers 2 x 2.6 lb
Grinders 2 titanium burr grinders
Steam arm 1 manual steam arm
Water spout 1 volumetric water spout
Soluble hopper and mixer 1
Display 7-inch touchscreen interface
Customizable drinks Up to 48 individual customizable drinks
Wash cycles Automatic coffee, milk, and soluble circuit wash cycles
WiFi connectivity Bidirectional WiFi with remote monitoring capabilities
Programming port USB
Water connection 3/8 in FBSP
Power 3.2-3.8 kW
Voltage 220-240 V
Frequency 50/60 Hz
Phase Single phase
Current 16 A
Plug NEMA 6-20P
Work surface High-polish stainless steel
Construction Black powder-coated steel

Certifications & Compliance

Certified badge of UL Certified
UL Certified

Frequently Asked Questions

It is a 1-group super-automatic espresso machine.
Yes. It has single-step soluble operation with one soluble hopper and mixer.
The machine supports up to 48 individual customizable drinks.
It has a 7-inch touchscreen interface with a customizable display.
Yes. It provides bidirectional WiFi connectivity with remote monitoring capabilities.
The coffee, milk, and soluble circuits have automatic wash cycles.
The machine is rated for 220-240 V, 50/60 Hz, single phase, 16 A, with a 3.2-3.8 kW power range and NEMA 6-20P plug.
