Montague Company

Montague Company Legend V136-14 36" Gas Range with 2 Open Burners, 18" Hot Top and Convection Oven

SKU: V136-14
$18,526.80
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

The Montague Legend V136-14 is a 36-inch gas range with two 18-inch, 30,000 BTU/hr open burners on the left, an 18-inch ring-and-cover hot top on the right, and a convection oven base.

Construction includes a stainless steel front, sides, burner box assembly, and bottom, plus a 4-inch stainless steel flue riser, drip tray components, deflector shields, burner supports, and 6-inch adjustable stainless steel legs.

  • Indirect-fired convection oven with blower
  • Three wire oven racks standard with five-position adjustable rack supports
  • 135,000 BTU/hr total input

Overall Dimensions:

36.0"W x 37.25"D x 36.0"H

Product Weight:

715.0 lb

Open burner top

Left-side top section has two lift-off 30,000 BTU/hr star burners with automatic standing pilots.

Ring-and-cover hot top

Right-side 18-inch hot top has a heavy-duty cast iron precision-ground plate with a removable front-positioned ring and cover.

Convection oven

Indirect-fired convection oven uses a blower and includes a counterweighted door, five-position rack supports, and three wire racks standard.

Stainless steel construction

The authoritative product specification identifies stainless steel for the front, sides, burner box assembly, and bottom, with a stainless steel flue riser.

Adjustable legs

Includes 6-inch adjustable stainless steel legs.

Gas input

Total rated input is 135,000 BTU/hr.

Commercial certifications

Certified or listed to CE, NSF, and cETLus requirements.

Related Searches

Best Sellers Commercial Gas Ranges Commercial Ranges Commercial Ranges Cooking Equipment Equipment Gas Ranges Gas Ranges Montague Company New Arrivals Ranges Restaurant Equipment
Fuel type Gas
Width 36 in
Depth 37.25 in
Height 36 in
Product weight 715 lb
Open burners 2 x 30,000 BTU/hr
Open burner section 18 in wide
Hot top 18 in ring-and-cover hot top
Hot top burner input 35,000 BTU/hr
Oven type Indirect-fired convection
Oven cooking compartment 26-5/8 in W x 22-1/4 in D x 15 in H
Oven burner input 40,000 BTU/hr
Total input 135,000 BTU/hr
Oven rack supports Five-position adjustable
Standard oven racks Three wire racks
Legs 6 in adjustable stainless steel
Flue riser 4 in stainless steel
Electrical 120 V, 1 phase, 60 Hz, 3.4 A
Power cord 6 ft with 3-prong NEMA 5-15P plug
Gas manifold 1-1/4 in NPT front manifold with 1/2 in union at each end

Certifications & Compliance

Certified badge of NSF Certified
NSF Certified

Warranty & Protection

Montague's limited original warranty is 12 months from the date of installation and no longer than 48 months from the date of manufacture.

Documents

PDF Cutsheet PDF Download PDF Owner's manual PDF Download PDF Warranty sheet PDF Download

Frequently Asked Questions

The range has two 18-inch, 30,000 BTU/hr open burners on the left, an 18-inch ring-and-cover hot top on the right, and a convection oven base.
It has an indirect-fired convection oven with a blower, a 40,000 BTU/hr cast iron burner, five-position adjustable rack supports, and three wire racks standard.
The total rated input is 135,000 BTU/hr.
The product is 36 inches wide, 37.25 inches deep, and 36 inches high, with a listed weight of 715 pounds.
The V136-14 is listed with CE, NSF, and cETLus certifications.
