Key specifications
- Amps
- 63 Amps
- Phase
- 3-Phase
- Dimensions
- 65.25"W × 49.23"D × 41.9"H
- Type
- Conveyor Oven
- Style
- Ventless
- Installation Type
- Floor Model
Spec sheet
Middleby Marshall PS638EV-2 Ventless Electric Double-Deck Conveyor Oven, 38-Inch Chamber, 26-Inch Belt, Floor Model
Questions before you buy?
Talk to an equipment specialist about voltage, installation or the right size for your kitchen.
Usually within 1 hour, 9am–6pm EST.
Specifications
Description
The Middleby Marshall PS638EV-2 is a ventless electric double-deck conveyor oven with a 38-inch cooking chamber and a 26-inch-wide standard single belt on each deck.
Electronic control provides a 30-second to 13-minute time range and a 325°F to 600°F operating temperature range. The oven has a front loading window and stainless steel front, sides, top, and interior.
- Includes top, legs, casters, and base.
- Impingement PLUS air delivery and ventless operation.
- Removable drip trays, crumb trays, end panels, air fingers, and conveyor belt support cleaning.
The manufacturer lists a one-year parts and labor warranty, including start-up and demonstration in the U.S. only.
Overall Dimensions:
65.25"W x 49.23"D x 41.9"HProduct Weight:
820.0 lbVentless Operation
Internal systems destroy grease-laden vapor before it escapes. The manufacturer notes that ventless certification excludes foods classified as fatty raw proteins and recommends consulting local HVAC codes and authorities for those foods.
Double-Deck Configuration
The oven is specified with two decks and a standard single 26-inch-wide belt on each deck.
Impingement PLUS Air Delivery
Airflow in the baking chamber can be modified through the main control.
Electronic Control
Electronic control provides adjustable time and temperature settings.
Temperature and Time Control
The operating temperature range is 325°F to 600°F, with a conveyor time range of 30 seconds to 13 minutes.
Front Loading Window
A front loading window is included.
Removable Cleaning Parts
Removable drip trays, crumb trays, end panels, air fingers, and conveyor belt support cleaning.
Included Components
Includes the top, legs, casters, and base.
