Middleby Marshall PS2620E-2 Double Deck Countertop Electric Conveyor Oven

SKU: PS2620E-2
$31,379.00
/each
Discontinued
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

Related Searches

Middleby Marshall New Arrivals

Middleby Marshall PS2620E-2 Double Deck Countertop Electric Conveyor Oven

26-Inch Cooking Chamber, Touch Screen Controls, 208/240V, 3-Phase

A space-saving, high-volume electric conveyor oven that delivers fast, consistent results with touchscreen control and reversible feed.

  • Countertop electric conveyor oven built for high-volume production in a compact footprint.
  • Double-deck design helps maximize output without taking up extra floor space.
  • 26-inch cooking chamber and variable-speed impingement airflow promote even baking.
  • Touch screen controls make it easy to adjust bake time, conveyor speed, and temperature.
  • Reversible conveyor direction supports left- or right-feed kitchen layouts.
  • Built-in diagnostics, idle mode, and cool-to-touch panels support efficient daily operation.

Overall Dimensions:

48.0"W x 41.8"D x 17.0"H

Product Weight:

260.0 lb

Touch Screen Controller

Intuitive interface for adjusting bake time, temperature, and conveyor speed.

Variable-Speed Impingement Airflow

Recirculating high-velocity airflow helps deliver fast, even cooking results.

Reversible Conveyor Direction

Software-controlled conveyor direction supports left or right feed setups.

26-Inch Cooking Chamber

Compact chamber size supports high-volume output in a countertop footprint.

Stackable Design

Can be stacked up to 2 high with stacking kits to expand throughput.

Built-In Self Diagnostics

Monitors oven components to help simplify troubleshooting and service.

Mono-Finger Conveyor Design

Easy-to-clean conveyor design helps reduce cleaning time.

Idle Mode and Cool-To-Touch Panels

Idle mode helps conserve energy, while exterior covers and panels are designed to stay cooler.

Stainless Steel Construction

Durable stainless steel build supports demanding commercial kitchen use.

Optional Ventless Operation

UL (KNLZ) listed for ventless operation when used with the optional catalytic converter.

Includes Plug and Cord

Includes a 6-foot nominal plug and cord for installation.

Smart Voltage Sensor Technology

U.S.-only technology helps the oven adapt to the available supply voltage.

Type Conveyor Oven
Style Double Deck
Installation Type Countertop
Material Stainless Steel
Controls Touch Screen
Airflow System Variable-Speed Recirculating Impingement
Temperature Range 0°F to 550°F
Time Range 30 Seconds to 15 Minutes
Cooking Chamber Length 26 Inches
Belt Width 26 Inches
Belt Length 48.4 Inches
Voltage 208/240 Volts
Amps 40 Amps
Watts 14.4 kW
Hertz 50/60 Hz
Phase 3-Phase
Plug Type NEMA 15-50P
Width 48 Inches
Depth 42 Inches
Height 17 Inches
Weight 260 lb.
Selling Unit Each
Units Per Case 1

Certifications & Compliance

Certified badge of UL Certified
UL Certified

Warranty & Protection

1-year parts and labor

Documents

PDF Cutsheet PDF Download PDF Middleby financial flyer PDF Download

Frequently Asked Questions

It uses 208/240 Volts, 3-Phase, 50/60 Hz, 40 Amps, with a NEMA 15-50P plug type.
The oven operates from 0°F to 550°F.
The time range is 30 seconds to 15 minutes.
Yes. The conveyor direction can be switched via software for left or right feed.
Yes. It has a stackable design up to 2 high with stacking kits, and ventless operation is available with the optional catalytic converter.
The cutsheet lists a 1-year parts and labor warranty.
