Micro Matic CDI2454-BF Beverage Trunk Line, 5/16" I.D., 24 Product Lines, 5 Glycol Lines, Aluminum Foil Wrap
- Product line diameter
- 5/16 in. I.D.
- Product lines
- 24
- Tubing type
- Barriermaster Flavourlock
- Glycol cooling line size
- 3/8 in. I.D. x 1/2 in. O.D.
- Glycol tubing material
- Polyethylene
- Glycol outgoing line color
- Blue
Specifications
Description
The Micro Matic CDI2454-BF is a Barriermaster Flavourlock trunk line for beverage delivery from a walk-in to a tower. It provides 24 product lines with 5/16 in. I.D. tubing and glycol cooling lines.
Color-coded lines support identification, while aluminum foil wrap conducts cold transfer from the glycol lines to the product lines. The assembly also uses moisture barrier wrap, closed-cell insulation, and a black tape jacket.
- NSF/ANSI Standard 51 Food Equipment Materials certification
- Sequential foot marking every 610 mm (2 ft.)
Overall Dimensions:
24.0"W x 12.0"D x 12.0"HProduct Weight:
2.5 lb24 product lines
Provides 24 beverage product lines.
Barriermaster Flavourlock tubing
Uses 5/16 in. I.D. tubing described as preventing gas permeation to help preserve beverage quality.
Color-coded lines
Product lines are color-coded and identified for easier line recognition.
Glycol cooling lines
Uses 3/8 in. I.D. x 1/2 in. O.D. polyethylene glycol tubing with blue outgoing and red return color coding.
Aluminum foil cold transfer wrap
Conducts cold transfer from the glycol lines to the product lines.
Moisture barrier and insulation
Includes a food-quality moisture barrier wrap and 3/4 in. closed-cell insulation.
Black tape jacket
Protects the insulation from tearing.
Sequential foot marking
Includes sequential foot marking every 610 mm (2 ft.).
