Master-Bilt FLR-60SE Flavorail Ice Cream Dipping Cabinet, 5 Tub Display / 7 Tub Storage, All Stainless Exterior

Self-Contained Cold-Wall Refrigeration, 115V, 1/4 HP

A durable, self-contained dipping cabinet that keeps 5 display cans and 7 storage cans ready to serve in an all-stainless package.

  • Displays (5) 3-gallon cans and stores (7) more 3-gallon cans.
  • SE model features an all stainless steel exterior with a galvanized steel inner liner.
  • Self-contained cold-wall refrigeration uses R290 refrigerant and holds 10°F to -10°F.
  • Stainless steel hinged lid includes handles and a heavy-duty replaceable gasket.
  • Anti-condensate heated top helps reduce moisture buildup on the work surface.
  • 115V, 1-phase plug-in operation with 8-foot cord and NEMA 5-15P plug.

Overall Dimensions:

43.0"W x 30.13"D x 38.25"H

Product Weight:

300.0 lb

All Stainless Steel Exterior

SE suffix version with a stainless exterior for durability and easy cleaning.

Galvanized Steel Inner Liner

Galvanized interior liner supports refrigerated cabinet construction.

Self-Contained Cold-Wall Refrigeration

Factory-tested, slide-out refrigeration system with cold wall evaporator and forced-draft hermetic condensing unit.

R290 Refrigerant

Uses R290 refrigerant for the refrigeration system.

5 Display / 7 Storage Can Capacity

Sized for 9-1/2 inch diameter, 3-gallon cans with display and reserve storage space.

Stainless Steel Hinged Lid

Stainless lid with handles and a heavy-duty replaceable gasket helps seal in cold air.

Anti-Condensate Heated Top

Heated stainless top cap helps reduce condensation during service.

Foamed-In-Place Insulation

2-1/4 inch urethane insulation helps maintain cabinet temperature.

Leveling Legs and Floor Drain

Leveling legs help correct unlevel flooring, and the floor drain includes a standard garden hose fitting.

Type Ice Cream Dipping Cabinet
Style Chest
Installation Type Floor Model
Refrigeration Type Self-Contained
Refrigerant Type R290
Capacity 5 3-Gallon Cans Display / 7 3-Gallon Cans Storage
Material Stainless Steel
Interior Finish Galvanized Steel
Finish Stainless Steel
Horsepower 1/4 HP
Voltage 115 Volts
Amps 3.2 Amps
Hertz 60 Hz
Phase 1-Phase
Plug Type NEMA 5-15P
Cord Length 8 Feet
Temperature Range 10°F to -10°F
Shipping Width 43 Inches
Shipping Depth 31 Inches
Shipping Height 39 Inches
Shipping Weight 300 lb.
Selling Unit Each
Units Per Case 1

Certifications & Compliance

Certified badge of NSF Certified
NSF Certified

Warranty & Protection

2-year parts and labor, plus 3 additional years on the compressor part.

Documents

PDF Cutsheet PDF Download PDF Cutsheet PDF Download PDF Lid lock installation manual PDF Download PDF Installation manual PDF Download PDF Owner's manual PDF Download PDF Warranty PDF Download

Frequently Asked Questions

No. The base model is sold less jars, pumps, and spoons.
It operates on 115/60/1 power, draws 3.2 amps, and includes an 8-foot cord with a NEMA 5-15P plug. A 15 amp service is recommended.
The cabinet is designed to hold product between 10°F and -10°F.
It uses a self-contained, slide-out, factory-tested refrigeration system with a cold wall evaporator and R290 refrigerant.
The SE suffix indicates an all stainless steel exterior.
Yes. The cabinet requires a minimum of 4 inches clearance between the back of the cabinet and the wall.
