Mars Air Systems STD272-2UD-OB Unheated Air Curtain for 72 in Door, Dual 1/2 HP Motors
STD272-2UD-OB is a Mars Air Systems Standard Series 2 unheated air curtain specified for a 72 in door. It uses two 1/2 HP motors and a galvanized steel cabinet with an Obsidian Black powder coat finish.
- 208-230 V, 60 Hz, single-phase electrical configuration
- 1.0 kW and 5.0 A
- Maximum opening height of 12 ft
- Adjustable air directional vanes with a 40° sweep front to back
The unit is listed with cETLus certification and an AMCA Certified Ratings Seal.
Overall Dimensions:
72.0"W x 12.75"D x 12.13"HUnheated configuration
The product is specified as unheated.
72 in door size
The unit is specified for a 72 in door.
Dual 1/2 HP motors
Two 1/2 HP motors are specified.
Adjustable air direction
Adjustable air directional vanes provide a 40° sweep front to back.
Motor construction
The series specifies continuous-duty Totally Enclosed Air Over motors rated NEMA 1.
Cabinet finish
The cabinet is galvanized steel with an Obsidian Black powder coat finish.
Parts warranty
A 5-year parts warranty is specified.
Certifications & Compliance
Warranty & Protection
5-year parts warranty
