Key specifications
- Amps
- 2.4 Amps
- Phase
- 3-Phase
- Dimensions
- 108.0"W × 12.75"D × 12.13"H
- Type
- Air Curtain
- Style
- Unheated
- Installation Type
- Wall Mounted
Spec sheet
Mars Air Systems STD2108-3UH-OB Air Curtain, 108" Door, Unheated, 3 x 1/2 HP Motors, Galvanized Steel Cabinet
Questions before you buy?
Talk to an equipment specialist about voltage, installation or the right size for your kitchen.
Usually within 1 hour, 9am–6pm EST.
Specifications
Description
The Mars Air Systems STD2108-3UH-OB is an unheated air curtain for a 108-inch-wide door opening. It has a galvanized steel cabinet with an Obsidian Black powder coat finish and three 1/2 HP continuous-duty TEAO motors.
This wall-mounted unit operates at 460 volts, 60 Hz, three-phase power and draws 2.4 amps. Adjustable air directional vanes provide a 40° front-to-back sweep.
- Maximum opening height: 12 ft
- 5-year parts warranty
- cETLus certified
Overall Dimensions:
108.0"W x 12.75"D x 12.13"HProduct Weight:
175.0 lbUnheated Operation
Designed without a heating function for unheated air curtain applications.
108-Inch Coverage
Sized for a 108-inch-wide door opening.
Three-Motor Configuration
Uses three 1/2 HP continuous-duty TEAO motors with NEMA 1 motor enclosures.
Adjustable Air Direction
Directional vanes provide a 40° sweep from front to back.
Galvanized Steel Cabinet
The cabinet has an Obsidian Black powder coat finish.
Opening Height
Listed for openings up to 12 ft high.
