Mars Air Systems

Mars Air Systems STD2108-3UA-OB Unheated Air Curtain, 108 in W, 12 ft Max Opening, 3 × 1/2 HP Motors, Black

SKU: STD2108-3UA-OB
$2,772.00
/each
Enter ZIP for a shipping estimate
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

Related Searches

Air Doors Best Sellers Equipment Facility & Ventilation Equipment Facility Air Curtains Kitchen Ventilation & Climate Control Mars Air Systems New Arrivals Restaurant Equipment

The Mars Air Systems STD2108-3UA-OB is an unheated Standard 2 air curtain sized for a 108 in wide door opening and environmental separation up to 12 ft.

  • Galvanized steel cabinet with an Obsidian Black powder coat finish.
  • Three 1/2 HP motors with a 115 V, 60 Hz, single-phase electrical configuration.
  • Adjustable air directional vanes with a 40° sweep from front to back.
  • Physical dimensions are 108 in W × 12.75 in D × 12.13 in H.

The unit has cETLus certification and a 5-year parts warranty.

Overall Dimensions:

108.0"W x 12.75"D x 12.13"H

Unheated configuration

Configured as an unheated air curtain.

108 in width

Sized for a 108 in wide door opening.

12 ft environmental separation

Listed for environmental separation up to 12 ft.

Three 1/2 HP motors

Uses three 1/2 HP motors.

Electrical configuration

Operates at 115 V, 60 Hz, single-phase with 15.3 A full-load amperage.

Obsidian Black finish

Features a galvanized steel cabinet with an Obsidian Black powder coat finish.

Adjustable air vanes

Air directional vanes provide a 40° sweep from front to back.

AMCA-rated data

AMCA-certified laboratory data is provided for the model; ratings apply at free delivery.

Product series Standard 2
Type Unheated air curtain
Maximum opening height 12 ft
Motors 3
Horsepower per motor 1/2 HP
Voltage 115 V
Frequency 60 Hz
Phase Single-phase
Power rating 1.5 kW
Full-load amperage 15.3 A
Cabinet material Galvanized steel
Finish Obsidian Black powder coat
Motor type Continuous-duty TEAO, NEMA 1
Air directional vane sweep 40° front to back
Maximum core velocity at nozzle 5,960 fpm
Average outlet velocity 2,206 fpm
Air volume 4,137 cfm
Velocity uniformity 84%

Certifications & Compliance

Warranty & Protection

5-year parts warranty

Documents

PDF Cutsheet PDF Download PDF Std2 unheated submittals PDF Download PDF Marketing sheet PDF Download PDF Collateral refrigeration PDF Download PDF Collateral PDF Download PDF Video PDF Download

Frequently Asked Questions

No. It is an unheated air curtain.
It is sized for a 108 in wide door opening.
It is listed for environmental separation up to 12 ft.
It uses 115 V, 60 Hz, single-phase power with 15.3 A full-load amperage and a 1.5 kW power rating.
It has three 1/2 HP motors.
The dimensions are 108 in W × 12.75 in D × 12.13 in H.
It has an Obsidian Black powder coat finish on a galvanized steel cabinet.
The product has a 5-year parts warranty.
