Mars Air Systems QP10144-3UG-AL Unheated Air Curtain for 144" Door, Anodized Aluminum Cabinet, 3 x 1/2 HP Motors

SKU: QP10144-3UG-AL
$5,313.00
/each
Enter ZIP for a shipping estimate
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

Related Searches

Air Doors Best Sellers Equipment Facility & Ventilation Equipment Facility Air Curtains Kitchen Ventilation & Climate Control Mars Air Systems New Arrivals Restaurant Equipment

The Mars Air Systems QP10144-3UG-AL is an unheated QuietPro air curtain specified for a 144-inch door opening. It has an anodized aluminum cabinet, three 1/2 hp motors, and 208-230 V, 60 Hz, 3-phase operation.

  • Integrated 24 V control circuit
  • Industrial magnetic switch 99-018 included
  • Adjustable air directional vanes with a 40-degree sweep front to back

Unheated operation

Designed as an unheated air curtain.

144-inch length

The model has a 144-inch nozzle length and 144-inch overall length.

Three motors

Uses three 1/2 hp continuous-duty Totally Enclosed Air Over motors with NEMA 1 construction.

Anodized aluminum cabinet

The cabinet has an anodized aluminum finish.

Integrated controls

Includes a factory-wired 24 V control circuit and industrial magnetic switch 99-018.

Adjustable air direction

Air directional vanes provide a 40-degree sweep from front to back.

Product type Air curtain
Series QuietPro 10
Operation Unheated
Door width 144 in
Maximum opening height 8 ft
Nozzle length 144 in
Overall length 144 in
Motors 3 motors
Horsepower per motor 1/2 hp
Motor type Continuous-duty TEAO, NEMA 1
Cabinet finish Anodized aluminum
Voltage 208-230 V
Frequency 60 Hz
Phase 3-phase
Control circuit 24 V
Magnetic switch 99-018, included
Air directional vane adjustment 40-degree sweep front to back
Intermediate supports 2
Maximum core velocity 4,247 fpm
Average velocity at nozzle 1,730 fpm
Air volume 4,326 cfm
Velocity uniformity 85%
Power rating 1,647 W
Weight 200 lb

Certifications & Compliance

Certified badge of ETL Listed
ETL Listed

Warranty & Protection

5-year parts warranty and 1-year warranty for 24 V control components.

Documents

PDF Cutsheet PDF Download PDF Qp10 unheated submittals PDF Download PDF Collateral PDF Download PDF Video PDF Download PDF Collateral refrigeration PDF Download PDF Marketing sheet PDF Download

Frequently Asked Questions

No. The QP10144-3UG-AL is an unheated air curtain.
It is specified for a 144-inch door opening, and the catalog lists a maximum opening height of 8 ft.
The exact model is specified for 208-230 V, 60 Hz, 3-phase operation.
It has three 1/2 hp motors.
Yes. Industrial magnetic switch 99-018 is included.
The product documentation lists a 5-year parts warranty and a 1-year warranty for 24 V control components.
