Key specifications
- Amps
- 1.8/1.6 Amps
- Phase
- 1-Phase
- Dimensions
- 48 in
- Type
- Air Curtain
- Style
- Unheated
- Material
- Aluminum
Spec sheet
Mars Air Systems PH1048-1UD-PW Unheated Air Curtain for 48 in Door, Aluminum Cabinet, 1/2 HP Motor
Questions before you buy?
Talk to an equipment specialist about voltage, installation or the right size for your kitchen.
Usually within 1 hour, 9am–6pm EST.
Specifications
Description
The Mars Air Systems Phantom 10 PH1048-1UD-PW is an unheated air curtain designed for a 48-inch door opening. It has an aluminum cabinet with a Pearl White powder coat finish, one continuous-duty 1/2 HP motor, and 208-230 Volt single-phase operation.
- Control: Integrated 24 Volt control circuit with magnetic switch 99-018.
- Air delivery: Adjustable directional vanes with a 40° front-to-back sweep, 1,632 CFM volume, and 3,895 FPM maximum core velocity.
- Certification: ETL and AMCA certified.
Product Weight:
120.0 lbUnheated Operation
The unit is an unheated Phantom 10 air curtain.
Aluminum Cabinet
The cabinet is constructed from aluminum and finished in Pearl White powder coat.
Single Motor
One continuous-duty 1/2 HP TEAO motor provides air movement.
Integrated Control Circuit
A factory-integrated 24 Volt control circuit is provided.
Magnetic Switch
Magnetic switch 99-018 is included for this unit.
Adjustable Air Direction
Directional vanes provide a 40° front-to-back sweep.
Cleanable Filter
A cleanable polyester filter is installed as standard.
Airflow Performance
The PH1048 model data lists 1,632 CFM volume and 3,895 FPM maximum core velocity.
