Mars Air Systems

Mars Air Systems NH284-2UH-TS Unheated Air Curtain for 84" Door, Two 1 HP Motors, Galvanized Steel Cabinet

SKU: NH284-2UH-TS
$3,402.00
/each
Enter ZIP for a shipping estimate
Want to speak to an expert?
(888) 307-5030
Chat
Bulk pricing available

Related Searches

Air Doors Best Sellers Equipment Facility & Ventilation Equipment Facility Air Curtains Kitchen Ventilation & Climate Control Mars Air Systems New Arrivals Restaurant Equipment

The Mars Air Systems NH284-2UH-TS is an unheated High Velocity Series 2 air curtain for an 84-inch door. It has a galvanized steel cabinet with a Titanium Silver powder coat finish and two 1 HP motors.

This model is sanitation certified to ANSI/NSF 37 standards and is specified for 460 V, 60 Hz, three-phase power.

Unheated operation

Provides an unheated air curtain configuration for an 84-inch door.

Sanitation certification

Sanitation certified to ANSI/NSF 37 standards.

Dual 1 HP motors

Uses two 1 HP continuous-duty Totally Enclosed Air Over motors with NEMA 1 construction.

460 V three-phase electrical specification

Specified for 460 V, 60 Hz, three-phase power.

Galvanized steel cabinet

Constructed with a galvanized steel cabinet and Titanium Silver powder coat finish.

Adjustable air direction

Air directional vanes provide a 40-degree sweep from front to back.

Parts warranty

Includes a 5-year parts warranty.

Series High Velocity Series 2
Product Type Unheated air curtain
Door Width 84 in
Motor Count 2
Horsepower per Motor 1 HP
Motor Type Continuous-duty TEAO, NEMA 1
Voltage 460 V
Frequency 60 Hz
Phase 3-phase
Cabinet Material Galvanized steel
Finish Titanium Silver powder coat
Nozzle Length 84 in
Overall Length 84 in
Max Core Velocity 6,051 fpm
Average Velocity 2,654 fpm
Air Volume 4,644 cfm
Velocity Uniformity 93%
Power Rating 2,610 W
Sound Level 73 dBA at 10 ft

Certifications & Compliance

Certified badge of ETL Listed
ETL Listed
Certified badge of NSF Certified
NSF Certified

Warranty & Protection

5-year parts warranty.

Documents

PDF Cutsheet PDF Download PDF Nh2 unheated sanitation submittal PDF Download PDF Collateral refrigeration PDF Download PDF Video PDF Download PDF Marketing sheet PDF Download PDF Collateral PDF Download

Frequently Asked Questions

No. The NH284-2UH-TS is an unheated air curtain.
It is specified for an 84-inch door.
It has two 1 HP motors.
The model is specified for 460 V, 60 Hz, three-phase power.
Yes. It is sanitation certified to ANSI/NSF 37 standards.
The listed product weight is 235 lb.
A 5-year parts warranty is listed.
