Play manufacturer video for Mars Air Systems NH236-1UA-TS Unheated Air Curtain, 36" Width, 8 ft Maximum Opening Height, 1 HP MotorMars Air Systems NH236-1UA-TS Unheated Air Curtain, 36" Width, 8 ft Maximum Opening Height, 1 HP Motor
SKU: NH236-1UA-TS
$1,474.20
/each
Enter ZIP for a shipping estimate
Expected delivery to by
Estimated Arrival
Estimated Cost
Finalize delivery options at checkout
The Mars Air Systems NH236-1UA-TS is an unheated High Velocity Series 2 air curtain for a 36 in. door with an 8 ft maximum opening height. It uses one 1 hp motor and 115 V single-phase power.
- Galvanized steel cabinet with Titanium Silver powder coat finish
- Sanitation certified to ANSI/NSF 37 standards
- Adjustable air directional vanes with a 40° sweep front to back
- cETLus and ETL certified
Unheated operation
The unit is specified as an unheated air curtain.
36 in. door coverage
The unit is specified for a 36 in. door and an 8 ft maximum opening height.
Single 1 hp motor
Uses one continuous-duty TEAO motor rated NEMA 1.
Sanitation certification
Specified as sanitation certified to ANSI/NSF 37 standards.
Galvanized steel cabinet
The cabinet has a Titanium Silver powder coat finish.
Adjustable air direction
Air directional vanes provide a 40° sweep from front to back.
Series
High Velocity Series 2
Type
Unheated air curtain
Maximum opening height
8 ft
Motor count
1 motor
Motor horsepower
1 hp
Motor construction
Continuous-duty TEAO, NEMA 1
Voltage
115 V
Frequency
60 Hz
Phase
Single phase
Full-load amperage
9.0 A
Cabinet material
Galvanized steel
Finish
Titanium Silver powder coat
Nozzle length
36 in.
Air volume
2,059 cfm
Maximum core velocity
6,000 fpm at nozzle
Average velocity
2,745 fpm
Velocity uniformity
90%
Power rating
1,245 W
Sound level
70 dBA at 10 ft in a free field
Certifications & Compliance
Warranty & Protection
5-year parts warranty.
Frequently Asked Questions
No. The NH236-1UA-TS is specified as an unheated air curtain.
It is specified for a 36 in. door and an 8 ft maximum opening height.
The unit is rated for 115 V, 60 Hz, single-phase power and has a 9.0 A full-load amperage.
It has one 1 hp continuous-duty TEAO motor rated NEMA 1.
The product is specified as sanitation certified to ANSI/NSF 37 standards.
The product documentation specifies a 5-year parts warranty.
