Play manufacturer video for Mars Air Systems NH2108-3UD-TS Unheated Air Curtain for 108" Door, 3 x 1 HP Motors, Galvanized Steel CabinetMars Air Systems NH2108-3UD-TS Unheated Air Curtain for 108" Door, 3 x 1 HP Motors, Galvanized Steel Cabinet
NH2108-3UD-TS is an unheated Mars Air Systems NH2 High Velocity Series 2 air curtain with a 108-inch nozzle length and overall length for a 108-inch opening.
It uses three 1 HP continuous-duty TEAO motors and is specified for 208-230 V, 60 Hz, single-phase power. The galvanized steel cabinet has a Titanium Silver powder coat finish, and adjustable vanes provide a 40-degree front-to-back sweep.
- Sanitation certified to ANSI/NSF 37 standards.
- AMCA lab data lists a 6,000 fpm maximum core velocity, 2,745 fpm average velocity, 6,177 cfm volume, and 90% velocity uniformity.
- ETL-certified for indoor and outdoor use.
Unheated operation
The NH2108-3UD-TS is an unheated air curtain.
Three 1 HP motors
Three continuous-duty Totally Enclosed Air Over motors are specified, with NEMA 1 designation.
Sanitation certification
The model is sanitation certified to ANSI/NSF 37 standards.
Galvanized steel cabinet
The cabinet is galvanized steel with a Titanium Silver powder coat finish.
Adjustable air direction
Adjustable air directional vanes provide a 40-degree sweep from front to back.
AMCA performance data
The model is included in the AMCA Certified Lab Data for the NH2 series.
Indoor and outdoor use
The documentation specifies ETL-certified use for indoor and outdoor applications.
Certifications & Compliance
Warranty & Protection
5-year parts warranty.
