Key specifications

Amps
15.3 Amps
Phase
1-Phase
Type
Air Curtain
Style
Unheated
Installation Type
Wall Mounted
Material
Galvanized Steel
Spec sheet
Mars Air Systems SKU: N2144-3UA-OB

Mars Air Systems N2144-3UA-OB Unheated Air Curtain for 144" Door, 3 Motors, 1/2 HP Each

$2,873.26
/each
Estimated to ship in 11–14 business days
Electrical
Motor fan assembly
Housing and finish
Door limit switches
Brackets

Need something else? Contact us.

Included: Mars Air Systems warranty 5-year parts warranty

Get priority processing and free 1-year protection with PREMIUM Learn about Premium

As low as $266/mo with Credit Key Learn more

Questions before you buy?

Talk to a specialist — usually within 1 hour, 9am–6pm EST.

Questions before you buy?

Talk to an equipment specialist about voltage, installation or the right size for your kitchen.
Usually within 1 hour, 9am–6pm EST.

Specifications

Type Air Curtain
Style Unheated
Installation Type Wall Mounted
Material Galvanized Steel
Country of Origin USA
Color Obsidian Black
Finish Powder Coat
Size 144 Inches
Horsepower Per Motor 1/2 HP
Motor Count 3
Motor Type Totally Enclosed Air Over (TEAO)
Voltage 115 Volts
Amps 15.3 Amps
Hertz 60 Hz
Phase 1-Phase
Watts 1.647 kW
Airflow 4,326 CFM
Maximum Core Velocity 4,247 FPM
Average Core Velocity 1,730 FPM
Velocity Uniformity 85%
Vane Sweep 40 Degrees

Description

Mars Air Systems N2144-3UA-OB is an unheated air curtain sized for a 144-inch-wide door. It uses three 1/2 HP continuous-duty TEAO motors and operates at 115 volts, 60 Hz, single phase.

  • Galvanized steel cabinet with an Obsidian Black powder coat finish.
  • Adjustable air directional vanes with a 40° sweep from front to back.
  • ETL-certified to ANSI/NSF 37, UL 507, and CSA 22.2 standards.
  • AMCA-certified to AMCA 211.
  • Includes a 5-year parts warranty.

Product Weight:

164.7 lb

Unheated Operation

Designed as an unheated air curtain.

Three-Motor Configuration

Uses three 1/2 HP continuous-duty Totally Enclosed Air Over motors.

Adjustable Air Direction

Directional vanes provide a 40° sweep from front to back.

Galvanized Steel Cabinet

The cabinet is made of galvanized steel and finished with Obsidian Black powder coating.

Certified Construction

Documented as ETL-certified to ANSI/NSF 37, UL 507, and CSA 22.2 standards, with AMCA certification to AMCA 211.

Warranty

Includes a 5-year parts warranty.

Frequently Asked Questions

No. The N2144-3UA-OB is an unheated air curtain.
It is designed for a 144-inch-wide door.
It has three 1/2 HP continuous-duty TEAO motors.
It operates at 115 volts, 60 Hz, single phase, with a listed full-load amperage of 15.3 amps.
The model is documented as cETLus and ETL-certified to ANSI/NSF 37, UL 507, and CSA 22.2 standards, and as AMCA-certified to AMCA 211.
A 5-year parts warranty is specified.

This ships by freight truck on a pallet, not by a parcel carrier. The carrier calls ahead to set a delivery window, and an adult 18 or older must be there to receive, inspect and sign for it.

The driver brings it to the back of the truck, or lowers it to the ground with liftgate service. They don’t bring it inside, so plan for a pallet jack or two people to move it from the curb.

What to have ready on delivery day

  • Count every piece against the delivery receipt.
  • Check every side for crushed corners, torn wrap, punctures, water stains or a tipped unit.
  • Photograph the freight on the truck before it’s moved.
  • If you see any damage, even cosmetic, write “DAMAGED” and what you see on the receipt before you sign.

Your shipping email has the exact instructions for your order. Questions at the door? Call us at (888) 307-5030.

How to inspect and sign for freight

Keep all the packaging, photograph the damage and the packaging, and tell us within 5 business days of delivery. Reply to your shipping email with the photos or call (888) 307-5030.

If the driver won’t wait while you inspect, write “Received – pending inspection. Driver would not wait.” with the date and time on the receipt, then inspect right away and report any damage within 24 hours.

Reporting damage after delivery

Book your installer only after the carrier gives you a firm delivery appointment. Freight dates can move, and installer trips lost to a late truck aren’t reimbursable.
