Play manufacturer video for Mars Air Systems N2108-3UD-OB Unheated Air Curtain, 108" Wide, 8 ft Opening, 3 MotorsMars Air Systems N2108-3UD-OB Unheated Air Curtain, 108" Wide, 8 ft Opening, 3 Motors
SKU: N2108-3UD-OB
$2,772.00
/each
Enter ZIP for a shipping estimate
Expected delivery to by
Estimated Arrival
Estimated Cost
Finalize delivery options at checkout
The Mars Air Systems N2108-3UD-OB is an unheated N2 Series air curtain for a 108-inch door and an 8-foot opening.
- Three 1/2 HP continuous-duty TEAO motors
- 208-230 V, 60 Hz, single-phase electrical configuration
- Galvanized steel cabinet with an Obsidian Black powder coat finish
- Adjustable air directional vanes with a 40° sweep front to back
- Sanitation certified to ANSI/NSF 37 standards
Unheated operation
The unit is designed as an unheated air curtain.
108-inch door coverage
Sized for a 108-inch door and an 8-foot opening.
Three-motor configuration
Uses three 1/2 HP continuous-duty TEAO motors.
Adjustable airflow direction
Air directional vanes provide a 40° sweep from front to back.
Galvanized steel cabinet
The cabinet has an Obsidian Black powder coat finish.
Sanitation certification
Certified to ANSI/NSF 37 standards.
Series
N2
Product type
Unheated air curtain
Door width
108 in
Maximum opening height
8 ft
Motors
3
Horsepower per motor
1/2 hp
Voltage
208-230 V
Frequency
60 Hz
Phase
1 ph
Cabinet material
Galvanized steel
Finish
Obsidian Black powder coat
Motor type
TEAO, NEMA 1, continuous duty
Air vane sweep
40° front to back
Weight
175 lb
Certifications & Compliance
Warranty & Protection
5-year parts warranty
Frequently Asked Questions
No. It is an unheated air curtain.
It is sized for a 108-inch door and an 8-foot opening.
It has three 1/2 HP motors.
It uses 208-230 V, 60 Hz, single-phase power.
The galvanized steel cabinet has an Obsidian Black powder coat finish.
The product includes a 5-year parts warranty.
