Mars Air Systems LPV296-2UD-OB Un-Heated Air Curtain for 96 in Door, 2 × 1/6 HP Motors
LPV296-2UD-OB is an unheated LoPro Series 2 air curtain specified for a 96 in wide door. It uses two 1/6 HP continuous-duty motors and operates on 208–230 V, 60 Hz, single-phase power.
The galvanized steel cabinet has an Obsidian Black powder coat finish. Standard features include a variable-speed controller with an off setting, an adjustable air directional vane, and a removable wall mounting bracket.
- Maximum opening height: 8 ft
- Overall length and nozzle length: 97.5 in
- Maximum air volume: 2,400 cfm
Product Weight:
115.0 lbUnheated operation
The unit is specified as an unheated air curtain.
Dual 1/6 HP motors
Uses two continuous-duty 1/6 HP motors.
Variable-speed control
Includes a variable-speed controller with an off setting.
Adjustable air direction
The air directional vane provides a 40° sweep from front to back.
Wall mounting bracket
Features a removable wall mounting bracket.
Obsidian Black finish
The galvanized steel cabinet has an Obsidian Black powder coat finish.
Certifications & Compliance
Warranty & Protection
5-year parts warranty.
