Play manufacturer video for Mars Air Systems LPN2108-2UA-OB Unheated Air Curtain, 108" Width, 8 ft Opening, 2 MotorsMars Air Systems LPN2108-2UA-OB Unheated Air Curtain, 108" Width, 8 ft Opening, 2 Motors
The Mars Air Systems LPN2108-2UA-OB is an unheated LoPro Series 2 air curtain designed for 108-inch-wide doors with a maximum opening height of 8 feet.
- Includes two 1/6 HP continuous-duty motors.
- Features a galvanized steel cabinet with an Obsidian Black powder coat finish.
- Operates on 115V, 60 Hz, single-phase power.
- Sanitation certified to ANSI/NSF 37 standards and cETLus listed.
Unheated operation
Provides unheated air curtain operation for the specified door application.
Two-motor configuration
Uses two 1/6 HP continuous-duty NEMA 1 motors.
Air performance
Rated for a maximum velocity of 1,800 fpm and a maximum air volume of 2,700 cfm.
Adjustable air direction
Includes an adjustable air directional vane with a 40-degree front-to-back sweep.
Cabinet and finish
Uses a galvanized steel cabinet with an Obsidian Black powder coat finish.
Wall mounting
Includes a removable wall mounting bracket.
Sound level
The 108- to 144-inch unit range is rated at 54 dBA measured at 10 feet in a free field.
Certifications & Compliance
Warranty & Protection
5-year parts warranty
