Play manufacturer video for Mars Air Systems HV296-2UA-TS Unheated Air Curtain, 96"W Door, 2 Motors, 1 HP EachMars Air Systems HV296-2UA-TS Unheated Air Curtain, 96"W Door, 2 Motors, 1 HP Each
The Mars Air Systems HV296-2UA-TS is an unheated High Velocity 2 air curtain designed for a 96-inch door opening. It features a galvanized steel cabinet with a Titanium Silver powder coat finish, two 1 HP motors, and 115 V single-phase electrical service.
- Supports environmental separation for openings up to 14 feet high.
- Model-specific performance data reports 4,894 cfm air volume and 6,144 fpm maximum core velocity.
- Adjustable air directional vanes provide a 40-degree front-to-back sweep.
Overall Dimensions:
96.0"W x 15.63"D x 14.0"HUnheated operation
The HV296-2UA-TS is an unheated air curtain.
Two-motor configuration
Uses two 1 HP continuous-duty TEAO motors with NEMA 1 construction.
96-inch model length
Designed for a 96-inch door opening.
Adjustable airflow direction
Air directional vanes provide a 40-degree front-to-back sweep.
Titanium Silver finish
The galvanized steel cabinet has a Titanium Silver powder coat finish.
AMCA-rated performance
The model is listed with AMCA certified laboratory performance data.
Certifications & Compliance
Warranty & Protection
5-year parts warranty.
