Key specifications
- Amps
- 3.3/3.2 Amps
- Phase
- 3-Phase
- Dimensions
- 48.0"W × 15.63"D × 14.0"H
- Type
- Air Curtain
- Style
- Unheated
- Installation Type
- Wall Mounted
Spec sheet
Mars Air Systems HV248-1UG-TS Unheated High-Velocity Air Curtain for 48" Door, 1 HP Motor
Questions before you buy?
Talk to an equipment specialist about voltage, installation or the right size for your kitchen.
Usually within 1 hour, 9am–6pm EST.
Specifications
Description
The Mars Air Systems HV248-1UG-TS is an unheated High Velocity 2 air curtain for a 48-inch door. It has a galvanized steel cabinet with a Titanium Silver powder coat finish and one 1 HP continuous-duty TEAO motor.
The unit is specified for 208-230V, 60 Hz, three-phase service. Adjustable air directional vanes provide a 40° sweep from front to back, and the unit can be fastened to a wall at both ends without intermediate support.
- Documented for environmental separation up to 14 ft and insect control up to 12 ft
- 5-year parts warranty
Overall Dimensions:
48.0"W x 15.63"D x 14.0"HProduct Weight:
144.0 lbUnheated Operation
The unit is specified as unheated.
48-Inch Door Size
The air curtain has a 48-inch nozzle and overall length for a 48-inch-wide door.
TEAO Motor
One 1 HP continuous-duty Totally Enclosed Air Over motor is provided with a NEMA 1 enclosure.
Adjustable Air Direction
Adjustable vanes provide a 40° sweep from front to back.
Galvanized Steel Cabinet
The cabinet is galvanized steel with a Titanium Silver powder coat finish.
Wall Fastening
The unit can be fastened to a wall at both ends without intermediate support.
Three-Phase Electrical Service
The specified electrical configuration is 208-230 Volts, 60 Hz, and 3-Phase.
Opening Height
The product documentation lists environmental separation up to 14 ft and insect control up to 12 ft.
Frequently Asked Questions
This ships by freight truck on a pallet, not by a parcel carrier. The carrier calls ahead to set a delivery window, and an adult 18 or older must be there to receive, inspect and sign for it.
The driver brings it to the back of the truck, or lowers it to the ground with liftgate service. They don’t bring it inside, so plan for a pallet jack or two people to move it from the curb.
- Count every piece against the delivery receipt.
- Check every side for crushed corners, torn wrap, punctures, water stains or a tipped unit.
- Photograph the freight on the truck before it’s moved.
- If you see any damage, even cosmetic, write “DAMAGED” and what you see on the receipt before you sign.
Your shipping email has the exact instructions for your order. Questions at the door? Call us at (888) 307-5030.
Keep all the packaging, photograph the damage and the packaging, and tell us within 5 business days of delivery. Reply to your shipping email with the photos or call (888) 307-5030.
If the driver won’t wait while you inspect, write “Received – pending inspection. Driver would not wait.” with the date and time on the receipt, then inspect right away and report any damage within 24 hours.
Book your installer only after the carrier gives you a firm delivery appointment. Freight dates can move, and installer trips lost to a late truck aren’t reimbursable.
