Legion TWWT-80MV | 80-Gallon Direct Steam Tilting Wall-Mount Kettle with Mixer
304 Stainless Steel • 2/3 Jacket • 30 psi Operating Pressure • Made in USADesigned for high-volume kitchens that refuse to compromise on durability or product consistency, the Legion TWWT-80MV combines an 80-gallon direct-steam, 2/3-jacketed kettle with an integrated twin-shaft, two-speed agitator. Wall-bracket mounting frees up valuable floor space, while the self-locking worm-gear tilt mechanism makes batch transfers smooth, safe and accurate.
Why You’ll Love It
- Unmatched Capacity: 80 gal / 303 L net capacity handles soups, sauces, stocks, chili & more.
- True 304 Construction: Seamless deep-drawn 304 kettle liner, 304L stainless jacket and seam-welded 304 support arms for maximum corrosion resistance.
- Built-In Mixing Power: Twin-shaft agitator with anchor-style main paddle, removable nylon scraper blades and counter-rotating beater for complete surface coverage.
- Two-Speed Gear Motor: 23 RPM low speed for delicate products, 60 RPM high speed for rapid dispersion (46/120 RPM shaft speeds at 15:1 gear ratio).
- Hands-Free, Precise Tilting: Reinforced stainless gear box with self-locking worm gear— eliminates drift and lets you stop exactly where you want.
- Space-Saving Wall Mount: Heavy-duty in-wall carrier keeps the floor clear and simplifies wash-down routines.
- ASME & NSF Compliant: Pressure-rated at 30 psi and fully certified for commercial kitchen use.
Integrated MV Mixer Highlights
- Balanced, enclosed aluminum mixer bridge—tilts out of the way for cleaning and batch change-overs.
- Bayonet-mount agitator & beater—no tools required for removal.
- Actuator-assisted lift raises mixer, scraper and bridge with minimal effort.
- Safety lockout prevents high-speed start-ups unless mixer is fully engaged.
- Scraper blades keep product off the sidewall to eliminate scorch and improve heat transfer.
Perfect For
- Soups, chowders & stews
- Custards, puddings & pastry creams
- Sauces, gravies & roux
- Pasta fillings & ricotta
- Batch beverages & concentrates
Technical Specifications
| Model | TWWT-80MV |
|---|---|
| Capacity | 80 gal | 303 L |
| Operating Pressure | 30 psi (2/3 jacket) |
| Jacket Coverage | 2/3 (sides & bottom) |
| Construction | 304 SS liner, 304L SS jacket, 304 SS arms & gear box |
| Mounting | Wall-bracket, seam-welded support arms |
| Tilting Mechanism | Self-locking worm gear, hand-crank |
| Agitator Type | Twin-shaft, anchor main with counter-rotating beater |
| Agitator Speeds | Low 23 RPM / High 60 RPM (main agitator) |
| Steam Connections | ¾" NPT inlet & outlet |
| Overall Width (F) | 53.3" / 135 cm |
| Overall Depth (C) | 46.3" / 118 cm |
| Height to Rim (A) | 32.5" / 83 cm (mounting height variable) |
| Shipping | Consult factory for crated weight & dimensions |
| Origin | Waynesboro, Georgia USA |
Steam supply, electrical hook-up and wall carrier hardware are sold separately. Contact your Legion representative for optional draw-off valves, faucet packages, higher pressure ratings or custom fabrication.
