Legion TWWT-50MV Steam Kettles
Description
Legion 50-Gallon Direct-Steam Tilting Wall-Mount Kettle Model TWWT-50 with MV Two-Speed Mixer
Built for high-volume, high-efficiency production, the Legion TWWT-50 combines powerful direct-steam cooking with an integrated twin-shaft agitator. The deep-drawn 304 stainless kettle, 2/3 jacket and self-locking worm-gear tilt deliver rapid, even heating and effortless product transfer, while the MV mixer keeps even the thickest recipes free from scorching or lumping. Wall-bracket installation frees up valuable floor space and positions the 50-gallon vessel exactly where your workflow needs it.
Key Performance Advantages
- 50 gal (189 L) capacity ideal for sauces, soups, fillings & ready-to-eat batches.
- 2/3-jacketed, direct-steam design reaches cooking temperature fast with superior heat distribution.
- Seamless 304 stainless steel liner & 304L jacket resist corrosion and simplify sanitation.
- Heavy-duty self-locking worm-gear tilt with control console allows safe, precise pouring.
- MV twin-shaft agitator (two-speed) keeps product homogenous while nylon scraper blades sweep the entire kettle surface.
- Wall-mount support arms are seam-welded to the jacket—no floor legs to clean around.
- ASME code-stamped 30 psi rating for reliable, long-term service.
- Made in the USA and NSF listed.
Integrated MV Mixer
- Anchor-style main agitator contoured to kettle wall (304 stainless).
- Counter-rotating secondary beater improves mixing of particulates.
- Bayonet-mount shafts lift out in seconds for cleaning or when kettle is used without agitation.
- Actuator-assisted bridge & agitator lift plus positive rim lock/latch for operator safety.
- Two-speed gear motor (High: 46 RPM main / 120 RPM beater • Low: 23 RPM main / 60 RPM beater) with up to 2 HP output.
Technical Specifications
| Capacity | 50 gal / 189 L |
|---|---|
| Construction | Seamless 304 SS liner, 304L SS 2/3 jacket, polished interior |
| Operating Pressure | 30 psi (206 kPa) max |
| Mounting | Wall-bracket, 304 SS support arms seam-welded to jacket |
| Tilt Mechanism | Manual worm-gear, self-locking, stainless gearbox |
| Steam Connection | ¾″ NPT inlet • ½″ NPT condensate outlet |
| Mixer Type | MV twin-shaft, two-speed, enclosed gear motor |
| Mixer Speeds | Low 23/60 RPM • High 46/120 RPM (main/secondary) |
| Mixer Horsepower | 3⁄4 HP (low) • 2 HP (high) |
| Overall Width (A) | 29.5″ (750 mm) |
| Overall Height (F) | 49.6″ (1 260 mm) to top of kettle body |
| Minimum Pour Path (X) | 37.8″ (960 mm) |
| Certifications | ASME, NSF, UL (motor), Made in USA |
Factory Options & Accessories
- 2″ or 3″ draw-off valve (compression or ball type)
- Single or dual fill faucets with 12″/18″ swing nozzle
- 48″ flexible spray hose assembly
- Automatic water-fill meter
- Lift-off or actuator-assisted cover
- Basket, tri-basket & nylon bag inserts
- Kettle care & cleaning kit
Need a custom feature? Legion offers extensive engineering options—just ask!
Warranty
Legion kettles include a 12-month parts & labor warranty from date of installation (15 months from shipment). Extended coverage is available.
